Asena
CC Syringe Pump - A Member of the Asena
®
Directions For Use - English
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Operating Precautions . . . . . . . . . . . . . . . . . . . . . 4
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Basic Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 8
Alarms and Warnings . . . . . . . . . . . . . . . . . . . . . . 9
Configured Options . . . . . . . . . . . . . . . . . . . . . 10 - 12
Drug Protocol Record . . . . . . . . . . . . . . . . . . . . . 13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Compatible Accessories . . . . . . . . . . . . . . . . . 15 - 17
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Occlusion Pressure Limits . . . . . . . . . . . . . . . . . 19
Self Test Routine . . . . . . . . . . . . . . . . . . . . . . . . . . 20
RS232/Nursecall Specification . . . . . . . . . . . . . . 20
Trumpet Curves . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Service Contacts . . . . . . . . . . . . . . . . . . . . . . . . . 22
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Pumps, Accessories and Spare Parts . . . . . . . . 24
1000PB00991 Iss. 5.0
Page
®
CC syringe pump . . . . 2 - 3
Introduction
®
®
The ALARIS
Asena
CC is a fully featured high end variable
pressure syringe pump suitable for critical care applications.
®
The Asena
CC syringe pump functions with a wide range of
standard, single-use, disposable Luer-lock syringes. It accepts
syringe sizes from 5ml to 50ml. A full list of compatible syringes
can be found on page 15.
Simple to set up and easy to operate.
Large graphics format display including pressure
trending.
Medical Device Interface (MDI) - a unique mounting
mechanism.
Rate Range from 0.1 to 1200ml/h.
In-line pressure monitoring from 0 to 1000 mmHg.
24 hour logging of volume infused.
Event logging records operation of pump.
Advanced Communications and Nursecall interfaces.
Configurable drug protocols for simplified drug
dosing.
Visit our website: www.alarismed.com
Infusion System
®
1/24
Advertisement
Table of Contents
Related Manuals for Alaris Medical Systems Asena CC
Summary of Contents for Alaris Medical Systems Asena CC
-
Page 1: Table Of Contents
Asena CC Syringe Pump - A Member of the Asena Infusion System ® ® Directions For Use - English Contents Introduction ® ® Page The ALARIS Asena CC is a fully featured high end variable pressure syringe pump suitable for critical care applications. Introduction . -
Page 2: Features Of The Asena ® Cc Syringe Pump
Features of the ALARIS ® Asena ® CC - Front View ON/OFF Pressure Release lever High visibility Display transducer for MDI Alarm Indicator PURGE/ BOLUS MUTE PRESSURE OPTION Extension HOLD Shelf for Syringe Clamp Positive Plunger set hook chevron keys Grippers and softkeys Controls and Indicators... - Page 3 Features of the ALARIS ® Asena ® CC - Rear View Medical Device Rating Plate (see Interface (MDI) - Symbol Definitions rotating cam to lock Pressure for an explanation of on to horizontal transducer the symbols used) rectangular bars. Release lever for IR Comms port Carrying...
-
Page 4: Operating Precautions
Operating Precautions In some circumstances the unit may be affected ® This ALARIS syringe pump has been by an electrostatic discharge through air at calibrated for use with single-use disposable levels close to or above 15kv; or by radio syringes. To ensure correct and accurate frequency radiation close to or above 10v/m. -
Page 5: Getting Started
Getting Started Front Panel and Main Display Syringe type fitted / Drug name Pump Status Time Remaining Icon Pressure Information 300mmHg Battery Icon Volume Infused VTBI Option Infusion Rate Volume Infused Option Installation There is a Medical Device Interface (MDI) at the rear of the Check that the pump is complete, undamaged and that the pump used for mounting the pump onto horizontal rectangular voltage rating specified on the base plate is compatible with... -
Page 6: Basic Features
Basic Features Starting the Pump Purge 1. Connect the pump to an AC power supply using the AC button allows the delivery of a limited volume of fluid in order to purge the extension line prior to being connected to power cable. - Page 7 Basic Features Pressure Level with pressure set fitted Set VTBI over Time This option allows you to specify a VTBI and delivery time. The 1. To check and adjust the pressure level press the button. rate necessary to deliver the required volume within the The display will change to show a 20 minute trend graph specified time is calculated and displayed.
- Page 8 Basic Features Drugs and Dosing Drugs and Dosing (cont.) The following options enable the unit to be set-up for use with User-programmed drug dosing: (available if Drugs are a specific drug and/or dosing protocol. Drugs are pre- configured) configured in a drug library (see Configured Options) to enable 1.
-
Page 9: Alarms And Warnings
Alarms and Warnings Alarms are indicated by a combination of an audible alarm, flashing alarm indicator and a descriptive message in the display. 1. First press the button to silence the alarm for a maximum of 2 minutes*, then check the display for an alarm message. Press CANCEL to cancel the alarm message. -
Page 10: Configured Options
Configured Options This menu comprises a list of options which are configurable by the user. 1. Turn the pump OFF. 2. Whilst holding down the button turn the pump ON. 3. The main display will show 000. Enter the access code for Configured Options using the keys, pressing NEXT to move through the digits. - Page 11 ® Asena CC Syringe Pump Configured Options Record Enter the pump-specific information for your General Options records on a copy of this page. Option Default Range Setting Software Version 1.5.10 & 2.0.0 1.8.x & 2.2.x NURSE CALL FITTED Disabled Disabled Enabled/Disabled NURSE CALL INVERT Disabled...
- Page 12 Configured Options Drug Library Clock Set 1. Select the DRUG LIBRARY option from the Configured 1. Select CLOCK SET from the Configured Options menu Options menu and press the OK softkey. using the keys and press the OK softkey. 2. To enter a new drug in the library press the NEW softkey. 2.
-
Page 13: Drug Protocol Record
Drug Protocol Record 13/24 1000PB00991 Iss. 5.0... -
Page 14: Specifications
Specifications Infusion Specifications - System Accuracy - Maximum infusion rate can be set as part of the configuration. Volumetric Mean +/- 2% (nominal). 0.1ml/h - 150ml/h 5ml syringes Derating - 0.1ml/h - 300ml/h 10ml syringes Temperature +/- 0.5% (5 - 40ºC) 0.1ml/h - 600ml/h 20ml syringes High Rates +/- 2.0% (rates >... -
Page 15: Compatible Accessories
Compatible Accessories The pump is calibrated and labelled for use with single-use disposable Luer-lock syringes. Only use the size and type of syringe specified on the pump display. The full list of permitted syringe models is dependent on the software version of the pump. 10ml 20ml 30ml... - Page 16 Compatible Accessories - Extension Sets The pump uses standard, single-use, disposable extension sets and syringes with Luer-lock connectors. The user is responsible ® for verifying the suitability of a product used, if it is not ALARIS recommended. Standard Sets G40015 Standard PVC Syringe Extension Set (150 cm).
- Page 17 Compatible Accessories - Extension Sets Continued The pump uses standard, single-use, disposable extension sets and syringes with Luer-lock connectors. The user is responsible ® for verifying the suitability of a product used, if it is not ALARIS recommended. Patient Controlled Analgesia (PCA) Sets 30822 PVC Syringe Extension Set with clamp (152 cm).
-
Page 18: Maintenance
Maintenance Routine Maintenance Procedures Replacing the AC Fuses To ensure that this instrument remains in good operating If the pump continually illuminates the battery symbol and the condition, it is important to keep it clean and carry out the AC power indicator light does not illuminate when the pump is routine maintenance procedures described below. -
Page 19: Occlusion Pressure Limits
Occlusion Pressure Limits Time to alarm following occlusion is achieved in less than 30 minutes at rates of 1 ml/h and higher by the appropriate selection of occlusion levels. Use of the dedicated pressure set is recommended. Its use permits the occlusion alarm pressure (mmHg) to be set accurately, with a small operating margin between the alarm and normal infusion pressures. -
Page 20: Self Test Routine
Test Routines RS232 / Nursecall Connection Data Nursecall Specification - The test routines are designed to allow confirmation of many of the pump functions, defaults and calibrations without requiring Connector D Type - 9 Pin internal inspection. They do not represent a full calibration TXD/RXD EIA RS232-C Standard check. -
Page 21: Trumpet Curves
Trumpet Curves & Start-up Curves In this instrument, as with all infusion systems, the action of the pumping mechanism and variations in individual syringes cause short-term fluctuations in rate accuracy. The following curves show typical performance of the system in two ways: 1) the delay in onset of fluid flow when infusion commences (start-up curves), and 2) the accuracy of fluid delivery over various time periods is measured (trumpet curves). -
Page 22: Service Contacts
Service Contacts ® ® For service contact your local ALARIS Medical Systems Affiliate Office or Distributor. ALARIS Medical Systems Service Centre Addresses: ALARIS Medical Systems Middle ALARIS Medical Deutschland, ALARIS Medical Italia S.P.A. ALARIS Medical Systems, Inc. East Office, GmbH,... -
Page 23: Warranty
(A) Each new infusion instrument (pump, controller or peripheral instrument) is free from defects in material and workmanship under normal use and service for a period of two (2) years from the date of delivery by ALARIS Medical Systems to the original purchaser. -
Page 24: Pumps, Accessories And Spare Parts
Pumps, Accessories and Spare Parts ® Please complete the details below and either fax or post this form to ALARIS Medical Systems or your nearest authorised distributor (see page 22). ALARIS Asena Infusion System Service Equipment ® ® ® The complete range of syringe pump products in the ALARIS ®...
