Unified Brands Randell RAN SCA-2 Operator's Manual

OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING R290 flammable refrigerant in use. Improper installation,
adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified
Brands suggests that if you are suspicious of damage to make a notation
on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
EQUIPMENT DESCRIPTION
OLD MODEL NEW MODEL
Closed Base - Steel
RAN SCA-2 RS SSC-RCP-2
RAN SCA-3 RS SSC-RCP-3
RAN SCA-4 RS SSC-RCP-4
RAN SCA-5 RS SSC-RCP-5
RAN SCA-6 RS SSC-RCP-6
Open Base - Steel
RAN SCA-2S RS SSO-RCP-2
RAN SCA-3S RS SSO-RCP-3
RAN SCA-4S RS SSO-RCP-4
RAN SCA-5S RS SSO-RCP-5
RAN SCA-6S RS SSO-RCP-6
Closed Base - Fiberglass
RANFG SCA-2 RS FGC-RCP-2
RANFG SCA-3 RS FGC-RCP-3
RANFG SCA-4 RS FGC-RCP-4
RANFG SCA-5 RS FGC-RCP-5
RANFG SCA-6 RS FGC-RCP-6
Open Base - Fiberglass
RANFG SCA-4S RS FGO-RCP-4
RANFG SCA-5S RS FGO-RCP-5
RANFG SCA-6S RS FGO-RCP-6
RECESSED COLD PANS
LENGTH DEPTH HEIGHT
36" 30" 35"
48" 30" 35"
60" 30" 35"
72" 30" 35"
84" 30" 35"
36" 30" 35"
48" 30" 35"
60" 30" 35"
72" 30" 35"
84" 30" 35"
36" 30" 35"
48" 30" 35"
60" 30" 35"
72" 30" 35"
84" 30" 35"
60" 30" 35"
72" 30" 35"
84" 30" 35"
Information contained in this document is known to be current and accurate at the time of printing/creation. Unified Brands recommends
referencing our product line websites, unifiedbrands.net, for the most updated product information and specifications. © 2019 Unified Brands.
All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
This manual provides information for:
RANSERVE MOBILE SERVING
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE: Due to a continuous program of product improvement, Unified Brands
reserves the right to make changes in design and specifications without prior notice.
NOTICE: Please read the entire manual carefully before installation. If certain
recommended procedures are not followed, warranty claims will be denied.
MODEL NUMBER _________________________
SERIAL NUMBER _________________________
INSTALLATION DATE ______________________
The serial number tag on Randell refrigerated
equipment is located in the mechanical housing. The
serial number tag on Randell hot food and silverware
stand are located on the far left front side of the unit.
The serial number tag on Randell cashier stands and
cold pans are located on the far left side.
12 X 20" PAN
HP VOLTS
CAPACITY
2 1/4 115/60/1
3 1/4 115/60/1
4 1/4 115/60/1
5 1/4 115/60/1
6 1/4 115/60/1
2 1/4 115/60/1
3 1/4 115/60/1
4 1/4 115/60/1
5 1/4 115/60/1
6 1/4 115/60/1
2 1/4 115/60/1
3 1/4 115/60/1
4 1/4 115/60/1
5 1/4 115/60/1
6 1/4 115/60/1
4 1/4 115/60/1
5 1/4 115/60/1
6 1/4 115/60/1
PART NUMBER PP MNL1902, REV. B (06/19)
AMPS NEMA SHIP WT
3.5 5-15P 250
3.5 5-15P 300
3.5 5-15P 350
3.5 5-15P 400
3.5 5-15P 450
3.5 5-15P 250
3.5 5-15P 300
3.5 5-15P 350
3.5 5-15P 400
3.5 5-15P 450
3.5 5-15P 250
3.5 5-15P 300
3.5 5-15P 350
3.5 5-15P 400
3.5 5-15P 450
3.5 5-15P 350
3.5 5-15P 400
3.5 5-15P 450
