11 | Keysight | Sourcing Precise Current/Voltage Sinusoidal Waveforms Using the B2961A/62A – Demo Guide
5) Press
,
,
6) Press
and select
pin is what we will configure.
7) Rotate
to select the Input/output function and press
to set the function to Trigger output.
8) Rotate
to select Polarity and press
to Positive; this will output a positive logic signal.
9) Rotate
to select the Pulse width of the phase marker output and press
Then enter 500 µs to set the Pulse width to 500 µs.
, and then press
to open the DIO Configuration dialogue.
(1) Press More...
(2) Press I/O
(3) Press DIO
(4) Press Config
to specify the Digital I/O pin number; the properties of this
to edit it. Then press
to edit it. Then press
to set the polarity
to edit it.
