Digital Mini Amplifier
Mini60
MIXING AMPLIFIER MINI60
USB
MIC
REC
MODE
VOL
User's Manual
Welcome to use DSPPA public address system. For the better use of this product, please read this instruction carefully
prior to use.
Guangzhou DSPPA Audio Co., Ltd
http://www.dsppatech.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini60 and is the answer not in the manual?

Questions and answers

Related Manuals for DSPPA Mini60

Summary of Contents for DSPPA Mini60

  • Page 1 Digital Mini Amplifier Mini60 MIXING AMPLIFIER MINI60 MODE User's Manual Welcome to use DSPPA public address system. For the better use of this product, please read this instruction carefully prior to use. Guangzhou DSPPA Audio Co., Ltd http://www.dsppatech.com...
  • Page 2 IP Network Ceiling Speaker Caution To assure the finest performance, please use or operate the product in accordance with corresponding instructions. This symbol indicates "forbidden content" This symbol indicates "compulsory content" ■ Please make sure that the ■ When the equipment is in use, DO NOT block the air power wire is NOT damaged.

  • Page 3: Table Of Contents

    IP Network Ceiling Speaker Content 1. Product Introduction ............................... 1 1.1 Introduction ..............................1 1.2 Features ................................ 1 2. Description of Appearance ............................. 2 2.1 Description of front panel ..........................2 2.2 Description of rear panel ..........................3 2.3 Description of remote ........................... 4 3.

  • Page 4: Product Introduction

    1.Product Introduction 1.1 Introduction MINI60 is a small acoustic amplification system featured by simplicity and high cost performance, and applicable to the small-sized broadcast system, the background music in the small-sized supermarket, and public address in the classroom. The system consists of the latest high-performance ARM core master control and high-efficiency energy-saving digital power amplifier circuit.

  • Page 5: Description Of Appearance

    2.Description of Appearance 2.1 Description of front panel MIXING AMPLIFIER MINI60 MODE USB interface It supports USB3.0, USB2.0 and the U-disk with the capacity less than 32G, with good compatibility. 2．Digital display screen It displays the status of the current mode.

  • Page 6: Description Of Rear Panel

    4Ω, which will cause the overloading protection of the system. The loudspeaker may be connected to 6 DSPPA (8Ω) ceiling speakers in two groups to the maximum extent. Please see the description below for the connection mode.

  • Page 7: Description Of Remote

    2.3 Description of remote Mute STOP Off/On Balance MODE Mode selection Previous Play mode Volume down Pause/Play Next Numbers Volume up Note： 1. On/Off: long press On/Off 2. Mute: close output of speakers 3. Mode selection: switch among LINE, USB, SD and BLUE 4.

  • Page 8: Operation Introduction

    3.Operation Introduction 3.1 Operation introduction of U Disk and SD mode (1) When the device is connected to power supply, open the power switch on rear panel. Press MODE to switch working mode. When U disk is inserted, press MODE to switch to U disk mode. Display screen will show LOAD (loading, please wait for 1-3 seconds) then it will enter USB play mode.

  • Page 9: Operation Instruction

    4.Operation Instruction 4.1 Connection of amplifier (The short circuit of the terminals between the left and right channels shall not be allowed; the output of the power amplifier is the bridging output; the negative output shall not be connected to the enclosure or grounded) 5.Working Mode 5.1 Microphone Broadcast Mode In case of the microphone broadcast in any mode, the system will test the voice of the microphone to mute the...

  • Page 10: Line Mode

    the SD card, it will switch over to the playing of SD card automatically. 5.4 Line Mode In the line mode, press the MODE key to enter, and the digital screen will display AUX.

  • Page 11: Safety Precautions

    For issues and precautions not mentioned in this User Manual, if required, please contact the distributor or visit our website at http://www.DSPPA.com  In case of any failure in the warranty period, please contact service personnel (or distributor) of our company for service.

  • Page 12: Packing List

    Packing List Item Quantity MINI60 Ampifier 20V/4.5A power adapter Power cable Infrared remote User manual Warranty card Certificate Installation screws Installation rubber nails 4P phoenix plug Specification Note: The performance specifications are subject to changes without further notification. Intem Indicator...
  • Page 13 ● This is connected to power source via the plug and any failure or danger occurs, the user can disconnect the device from power source by pulling out the plug out from the socket, therefore, it is required that the power socket should be located somewhere with easy access. Guangzhou DSPPA Audio Co., Ltd...
