- Page 1 SETUP INSTRUCTIONS 2017 1090 Adventure Art. no. 3213663en...
- Page 3 KTM accepts no liability for delivery options, devi- ations from illustrations and descriptions, misprints, and other errors.
-
Page 4: Means Of Representation
MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 SETUP Unpacking and setting up the vehicle – Remove the straps and box. F01037-10 – Remove the adhesive tape in the upper area of the motorcycle. F01038-01 – Roll down the film at the sides. Info To avoid damaging the motorcycle during unpacking, leave the other films on the vehicle until you have finished work on the vehicle.
- Page 6 SETUP Warning Danger of accidents A repaired handlebar poses a safety risk. If the handlebar is bent or straightened, the material becomes fatigued. The handlebar may break as a result. – Change the handlebar if the handlebar is damaged or bent. –...
- Page 7 Recharge the battery. ( p. 6) F01015-10 – Remove the remaining films. – Check the headlight setting. ( p. 9) – Refuel. ( p. 12) – Prepare the vehicle according to the specifications in the KTM Dealer.net for han- dover to the customer.
-
Page 8: Recharging The Battery
WORK Installing the wind shield – Position wind shield – Mount and tighten screws Guideline Screw, wind shield 3.5 Nm (2.58 lbf ft) F00669-11 Removing the seat – Insert the ignition key in the seat lock and turn it clockwise by 45°. –... - Page 9 WORK Info Even when there is no load on the battery, it discharges steadily. The charging level and the method of charging are very important for the service life of the battery. Rapid recharging with a high charging current shortens the service life of the battery. If the charging current, charging voltage, and charging time are exceeded, the battery will be destroyed.
- Page 10 WORK Preparatory work – Switch off the ignition by turning the black ignition key to the position OFF – Remove the seat. ( p. 6) Main work – Pull locking mechanism in the direction of the arrow. – Fold open cover D02869-10 –...
-
Page 11: Checking The Headlight Setting
WORK – Close the cover and push down slightly. The cover engages with an audible click. F00697-10 Finishing work – Mount the seat. ( p. 6) – Set the time and date. Checking the headlight setting – Park the vehicle on a horizontal surface in front of a light-colored wall and make a mark at the height of the center of the low beam headlight. - Page 12 WORK Removing the bottom triple clamp cover – Remove screws – Lower the triple clamp cover slightly. F00654-10 – Disconnect plugs of the horn. – Detach temperature sensor – Remove the triple clamp cover. F00655-10 3.10 Installing the bottom triple clamp cover –...
- Page 13 WORK Warning Danger of poisoning Fuel is poisonous and a health hazard. – Avoid skin, eye and clothing contact with fuel. – Immediately consult a doctor if you swallow fuel. – Do not inhale fuel vapors. – In case of skin contact, rinse the affected area with plenty of water. –...
- Page 14 WORK 3.13 Refueling Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not refuel the vehicle in the vicinity of open flames or lit cigarettes. – Switch off the engine for refueling. –...
-
Page 15: Technical Data
TECHNICAL DATA Chassis tightening torques – Screw, combination switch, left 2 Nm (1.5 lbf ft) – Screw, side stand switch 2 Nm (1.5 lbf ft) – Rear fairing screw M5x12 3.5 Nm (2.58 lbf ft) – Rear fairing screw M5x17 3.5 Nm (2.58 lbf ft) –... - Page 16 TECHNICAL DATA – Remaining chassis nuts 25 Nm (18.4 lbf ft) – Remaining chassis screws 25 Nm (18.4 lbf ft) – Screw, bottom triple clamp 12 Nm (8.9 lbf ft) – Screw, exhaust clamp 25 Nm (18.4 lbf ft) Screw, foot brake lever 25 Nm (18.4 lbf ft) Loctite ®...
- Page 17 SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
- Page 18 *3213663en* 3213663en 03/2017 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...
