Functional Description and Specifications

Disconnect the plug from the power source before making any assembly,
WARNING
!
adjustments or changing accessories. Such preventive safety measures
reduce the risk of starting the tool accidentally.
CONTROL DIAL
FIG. 1
LEFT
HANDLE
COARSE ADJUSTMENT
LOCK
SPINDLE LOCK
DIRECTION OF BIT
ROTATION
FIG. 2
"LOCK-ON"
BUTTON
ON/OFF TRIGGER
SWITCH
DUST EXTRACTION HOOD
Model number:
Voltage rating:
Amperage rating:
10/7/03 4:51 PM Page 7
Router
SPEED
COLLET
CHUCK
1619EVS
120 V 50 - 60Hz
15 A
-7-

FRONT VIEW

VENTS
FINE ADJUSTMENT KNOB
FINE ADJUSTMENT
COARSE ADJUSTMENT
COARSE ADJUSTMENT KNOB
SPRING DEFEAT BUTTON
DEPTH STOP TURRET

BACK VIEW

PLUNGE LOCK
OVERRIDE LEVER
PLUNGE LOCK
BASE
SUB-BASE
No load speed: n 8,000-21,000/min
0
Collet capacities: 1/4", 3/8", 1/2", 8mm
INDICATOR
RIGHT HANDLE
INDICATOR
LEVER
