Functional Description and Specifications

Disconnect the plug from the power source before making any
!
WARNING
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
FIG. 1
FINE
ADJUSTMENT
INDICATOR
DEPTH ROD
DEPTH SCALE
LEFT HANDLE
DEPTH
INDICATOR
DEPTH
INDICATOR
KNOB
TURRET
ADJUSTMENT
SCREW
DEPTH STOP
TURRET
FIG. 2
ON/OFF TRIGGER
SWITCH
Model number:
Voltage rating:
Amperage rating: 12 A
7/24/06 9:03 AM
Router
FINE ADJUSTMENT
KNOB

BACK VIEW

1613AEVS
120 V 60Hz
Page 7

FRONT VIEW

SUB-BASE
No load speed: n
Collet capacities: 1/4", 3/8", 1/2", 8mm
-7-
RIGHT HANDLE
"LOCK-ON"
BUTTON
SPEED
CONTROL DIAL
SPINDLE LOCK
CHIP SHIELD
DIRECTION OF BIT
ROTATION
LEFT
HANDLE
INDEX
MARKER
PLUNGE LOCK
LEVER
COLLET CHUCK
BASE
11,000-22,000/min
