en 10 | 0 986 610 511 | Product description
andrefraktometer
3. Product description
Scharfeinstellung
3.1 Intended use
O-Justierschraube
lplatte
The 0 986 610 511 handheld refractometer (he-
)
reafter referred to as 'handheld refractometer')
measures the urea content of the AdBlue urea
aqueous solution.
Prisma Gummi-Handgriff
!
Harmful or corrosive chemicals must not be
measured using the handheld refractometer.
eren Sie 2-3
ma. Schließen
3.2

Scope of delivery

eilt sich ohne
r die gesamte
Probe zum
Denomination
, bevor Sie mit
e, sich der
rs anzugleichen) Handheld refractometer
Cleaning cloth
schlecht schlecht gut
Pipette
Screwdriver
Original operating manual
Tab. 1: Scope of delivery
g einer
r. Sie werden ein
3.3

Device description

Mitte sehen
ulars einstellen,
n). Der obere Teil
n
ß sein. (Die
in Schritt 3 und
ge spezifische
Ansicht beim
,
Blick in das
Instrument
il
1
Ansicht beim
Blick in das
7
Instrument
Fig. 1: Handheld refractometer
1 Light incidence plate
2 0-adjustment screw
3 Rubber handle
4 "Urea content" scale in the eyepiece
5 Eyepiece
6 Focusing
7 Prism
1 689 989 328
Okular
schlecht schlecht gut
Order number
-
-
-
-
1 689 989 328
3
2
|
2016-12-12
4.

Operation

i
The ambient temperature must be around
20°C/68°F during the measurement.
i
For a precise measurement to be obtained,
careful calibration is required.
Measuring the urea content:
1. Lift up the light incidence plate.
2. Clean the prism with a clean cloth.
3. Place 2-3 drops of AdBlue on the prism using
the pipette provided.
4. Close the light incidence plate.
 AdBlue spreads across the entire surface
of the prism without air bubbles and dry
patches.
5. Wait 30 seconds.
 The temperature of the AdBlue adapts to
the ambient temperature of the handheld
refractometer.
6. Hold the light incidence plate up to a light
source and look into the eyepiece.
 The urea content is indicated by the light
area on the scale in the eyepiece (item 4,
Fig. 1).
i
The reference value of the urea con-
tent of AdBlue is around 32.5%. The
4
characteristic line (item 1, Fig. 2) on the scale
in the handheld refractometer indicates the
reference value.
5
6
Fig. 2:
i
The permissible deviation of 32.5% urea cont-
ent in AdBlue depends on the manufacturer.
7. Observe the manufacturer's specifications
for the change frequency of AdBlue and urea
content in AdBlue.
!
If the measured urea content deviates from
the manufacturer's specifications, the tested
AdBlue must no longer be used.
1
Characteristic line for the reference value of
urea content in AdBlue
