• AC – analog comparator Application Note 1 Introduction This application note is a guide to assist users of ATxmega128A1/64A1 in converting designs to Atmel ATxmega128A1U/64A1U. For complete device details, always refer to the most recent version of the ATxmega128A1U/64A1U datasheet ® ®...
2 Enhancements and added functions In this section, we summarize the enhancements or added features in Atmel ATxmega128A1U/64A1U compared with Atmel ATxmega128A1/64A1. For pure migration, you can skip the section and start from the next section. 2.1 USB • One USB 2.0 full speed (12Mbps) and low speed (1.5Mbps) device compliant interface is added 2.2 Clock system...
Atmel AVR1019 2.9 Power management • Possibility to enable sequential start of the components used for analog modules ADC and Analog Comparator in order to reduce start-up current 8415A-AVR-07/11...
LVTTL LVCMOS compatible Atmel ATxmega128A1U/64A1U devices. The minimum “Input High Voltage” is never higher than 2.0V for VCC > 2.7V. In Atmel ATxmega128A1/64A1, the minimum “Input High Voltage” is 0.7VCC, and could be higher than 2.0V for VCC>2.86V. 8415A-AVR-07/11...
5 DAC – digital to analog converter The Atmel ATxmega128A1U/64A1U DAC has two continuous output channels, and not a sample and hold circuit as Atmel ATxmega128A1/64A1 devices. This gives continuous time output and higher sample rate for each channel. There is separate calibration (offset/gain) for each DAC channel in ATxmega128A1U/64A1U.
Atmel AVR1019 6 AC – analog comparator In Atmel ATxmega128A1U/64A1U, there is a two-cycle delay from writing a new MUX setting until it takes effect. 8415A-AVR-07/11...
7 Registers 7.1 Removed registers and bits The below table lists register bits, which exist in Atmel ATxmega128A1/64A1 but not in Atmel ATxmega128A1U/64A1U. Table 7-1. Register bits and functionality that does not exist in ATxmega128A1U/64A1U. Register name Register bit Function...
