AVR1909: Display Xplained Hardware User's
Features
• 240 x 320 (QVGA) graphical TFT display
- With resistive touch
- LED Backlight
- Internal controller
• Simple SPI interface for control
• Digital (PWM) control interface for backlight
• One 40pin, 0.5mm FPC connector
• Display and backlight powered by single 3.3V
1 Introduction
The Display Xplained module gives the possibility to evaluate a 240 x 320 pixel
(QVGA) graphical RGB TFT display with a 4-wire touch interface and LED
backlight. The display is interfaced with a simple SPI interface to send and receive
commands and data. The Xplain kit provides tested low–level drivers and high-
level functions in order to get the developer quickly up to speed with his application
development.
Figure 1-1. Display Xplained evaluation module.
Guide
8-bit
Microcontrollers
Application Note
Rev. 8297A-AVR-04/10
Advertisement
Related Manuals for Atmel AVR1909
Summary of Contents for Atmel AVR1909
- Page 1 AVR1909: Display Xplained Hardware User's Guide Features • 240 x 320 (QVGA) graphical TFT display 8-bit - With resistive touch Microcontrollers - LED Backlight - Internal controller • Simple SPI interface for control • Digital (PWM) control interface for backlight Application Note •...
-
Page 2: Related Items
Datasheet for the graphical controller (HX8347-A) from Himax can be obtained by contacting EDT. It may also found on the web. Firmware for Xplain kit can be found here: http://www.atmel.com/Xplain Also checkout these application note: • AVR1913: Display Xplained Firmware – Getting Started training •... - Page 3 AVR1909 The Display Xplained module is quite simple. It basically connects the TFT display SPI interface, resistive touch interface, and backlight interface from a 40pin FPC connector to two female pin-headers that fit the Xplain kit. In addition it has a program/debug interface that will connect an external programmer/debugger to the Xplain kit through a male and a female pin-header.
- Page 4 3.4 The SPI interface The Display Xplained module uses a simple SPI interface to communicate with the LCD module. This consist of a Chip-Select (CS) line, a clock line (SCL), and two data lines (SDI/SDO). The SPI is operated in mode 3, i.e. inactive clock is ‘high’, and data is latched on rising clock edge.
- Page 5 J103/J104-9 J103/J104-10 Notes: 1. Standard pin-out for JTAGICE mkII and other Atmel programming tools. 2. Requires adapter or squid cable to connect a JTAGICE mkII (refer to AVR Studio help). 3. It is only required to connect one V3P3/GND pin.
- Page 6 5 Available code examples and drivers A Getting-Started training for the Display Xplained kit can be downloaded from the Atmel web site. The application note is called: AVR1913: Display Xplained Firmware – Getting Started training. Further information and drivers for Display Xplained can be downloaded as application notes, also distributed from Atmel’s web site.
