DRYER SUPPORT AND WASHER HARNESS PARTS
For Model: WGT3300SQ0
(Designer White)
Illus.
Part
No.
No.
DESCRIPTION
1 W10114956 Harness − Washer
1A
3350130 Plug, 3 Way
1B
3347243 Connector, 5 Way
1C
352089 Block,
Disconnect − Timer
1D
3350211 Receptacle, 3 Way
1E
62505 Block, Disconnect
2
3388851 Channel Assembly
(Left hand Side)
3
3388850 Channel Assembly
(Right Hand Side)
4
3390609 Shield, Harness
5
8545438 Hose, Pressure
Switch
6
8281256 Clip, Harness
7
343641 Screw, 10−16 x 1/2
13
3400300 Bolt,
5/16−18 x 1/2
14
3393930 Nut, Hex (4)
15
3392232 Shield, Front
16
3390336 Shield,
Thermostat
18
3391249 Clip, Harness (2)
19
3354925 Connector,
H−Pod
20
3360056 Connector,
Pressure Switch
23
Terminal,
94613 Male
94614 Female
24
63523 Protector,
Harness
8
W10120076
