Vendor: S000053
ASSEMBLY INSTRUCTIONS
ATLAS 4' BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR ATLAS 4' BED
FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
www.birlea.com
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATLAS and is the answer not in the manual?

Questions and answers

Related Manuals for Birlea ATLAS

Summary of Contents for Birlea ATLAS

  • Page 1 Vendor: S000053 ASSEMBLY INSTRUCTIONS ATLAS 4’ BED IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR ATLAS 4’ BED FRAME. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY: DO NOT jump on this bed frame. DO NOT use this bed frame if any parts are missing, damaged or worn.
  • Page 2 Vendor: S000053 Parts List Hardware List (found in box 1) Part Description Part Description Headend M6 x 16mm JCBC Screw Footend M6 x 50mm JCBC Screw Side Support M6 Nut Side Frame M6 x 35mm JCBC Screw Mid Support Double Slat Cap Base Leg Single Slat Cap Slat...
  • Page 3 Vendor: S000053 Step 2: Place the side frames (4) at the bottom of the side supports (3) and secure with hardware parts B and C. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 3: Place the mid support (5) on top of both side frames (4) and secure using hardware parts H and I.
  • Page 4 • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
