Birlea
Suppliers of Inspiration
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR
ATLAS 3'BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY :
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all
legs to stop the bed frame from moving. If this is not adhered to there is no guarantee if the bed
frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
ASSEMBLY INSTRUCTIONS
ATLAS 3'BED
Vendor: S000053
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATLAS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Birlea ATLAS

  • Page 1 Suppliers of Inspiration ASSEMBLY INSTRUCTIONS ATLAS 3'BED IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR ATLAS 3'BED FRAME. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY : DO NOT jump on this bed frame. DO NOT use this bed frame if any parts are missing, damaged or worn.
  • Page 2 Vendor: S000053 PART LIST HARDWARE LIST (FOUND IN BOX 1) PART DESCRIPTION PART DESCRIPTION Headend M8 x 20mm JCBC Screw M6 x 12mm JCBC Footend ∅2 2xM6x15mm Side Support Side Support Slat Cap Mid Support Side Frame Finials Slat IMPORTANT: DO NOT SCREW UP THE RACK TIGHTLY UNTIL ALL PARTS ARE WELL SET WITH PROPER HARDWARES IN PLACE!!!...
  • Page 3 Vendor: S000053 Step 1: Step 2: Page 3 of 4...
  • Page 4 Vendor: S000053 Step 3: Step 4: D x24 8 x12 D x 24 Page 4 of 4...
