ITEM NO. PART NO.
1 690671–1
2 690672–2
3 4–21002–4
4 3–21000–6
5 690673–2
6 2–21000–7
7 690674–1
8 21009–4
9 690499–1
10 ––
11 694925–1*
12 694928–2
13 470268–1
14 3–21000–1
15 27708–3
16 21022–2
17 455744–1
18 455745–1
19 1–21899–3
20 21018–6
21 7–22468–0
22 7–22468–3
23 22280–1
24 455748–1
25 455749–1
26 3–21002–4
27 21899–3
*Refer to Customer Manual 409–5128 for the detailed parts breakdown of assembly and related parts..
E
2009 Tyco Electronics Corporation, Harrisburg, PA
All International Rights Reserved
TE logo and Tyco Electronics are trademarks.
*Trademark. Other products, logos, and company names used are the property of their respective owners.
AMP-O-LECTRIC* Terminating Machine
Conversion Kits 690675-2 and 692613-1
for Miniature Quick-Change Applicators
PLATE, Base
MOUNT, Base
SCREW, Btn Hd Cap, 3/8–16 x .500 in. L
SCREW, Skt Hd Cap, No. 10–32 x .625 in. L
BRACKET, Hold–Down
SCREW, Skt Hd Cap, No. 8–32 x .500 in. L
STOP, Rear
SETSCREW, Skt, Slflkg, 1/4–20 x .375 in. L
RAM
Deleted
BRACKET ASSY, Vertical Reel
BRACKET, LH Stock Guide
GUIDE, Stock
SCREW, Skt Hd Cap, No. 8–32 x 1.00 in. L
KNOB, Thumbscrew
NUT, Slflkg, No. 8–32
SHROUD, End Feed
GUARD, End Feed
WASHER, Flat, No. 8
NUT, Hex, No. 8–32
SCREW, Bdg Hd, No. 8–32 x .375 in. L
SCREW, Bdg Hd, No. 8–32 x .750 in. L
SPRING, Compression
SHROUD, Side Feed
GUARD, Side Feed
SCREW, Btn Hd Cap, 1/4–20 x .625 in. L
WASHER, Flat, 1/4 in.
Figure 1
TOOLING ASSISTANCE CENTER 1-800-722-1111
PRODUCT INFORMATION 1-800-522-6752
DESCRIPTION
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.tycoelectronics.com
Instruction Sheet
408-8022
06 FEB 09 Rev A
QTY
1
1
3
2
1
2
2
1
1
––
REF
1
1
4
2
1
1
1
12
7
5
1
1
1
1
1
1
