TIS TERRE Series Installation Manual

INsTaLLaTIoN maNuaL
Terre Touch ThermosTaT
Model: TER-ACT
OLED
Touch
Input
TIS Bus
Protection
Operating and display
elements
Dimensions
Housing
BarcoDe (uPc-a)
6 58921 79803 4
A simple 4-touch button interface to control
temperature, fan speed, floor heating, or any
other heating and cooling devices. Reminders and
alerts are displayed on a 1" high-resolution OLED
screen.
P R O D U C T S P E C I F I C AT I O N S
Size
Active area
Touch Type
Temp sensor
Number of devices on 1 line
Bus voltage
Current consumption
touch buttons
Backlight
Width × length × height
Materials
Internal Parts color
IP rating
Automation Made Easy
ProDucT INFormaTIoN
0.9"
1.5"
Capacitive
Resistive Temp Sensor
Max. 64
12-32 V DC
<20 mA / 24 V DC
Reverse Polarity Protection
ESD Protection
4 touch buttons for AC control ...
Backlight indicators
45mm × 25mm × 45mm
PC anti fire / Glass in front
Black & gray
IP 50
