TIS MARS 10 GANGS Installation Manual

Wall panel with thermostat

Advertisement

Quick Links

INSTALLATION MANUAL
MARS 10 GANGS WALL PANEL WITH
THERMOSTAT
Model: MRS-AC10G
Input
Output
TIS Bus
Operating and display
elements
Functions
Dimensions
Housing
BARCODE (UPC-A)
6
58921
79749
5
Mars 10 Gang + AC is a 10-button panel with a
stylish 1" OLED touch screen and attractive icon
buttons. This device has an internal thermostat; it
can read the room temperature so that you can
manage your cooling and heating systems more
efficiently. You can also control your lights, curtains,
and scenarios with its other 10 push buttons.
P R O D U C T S P E C I F I C AT I O N S
Temp sensor
IR receiver
Using Panel Addition
Using Panel Addition 3R
Using Panel Addition 3DL-12V
Using Panel Addition 2DL-IRE
Number of devices on 1 line
Bus voltage
Current consumption
Display
12 Buttons
Indicator LED
Backlight
TIS bus
Upgrading
1 Press
Long Press
Double click
IR receiver
Width × length × height
Materials
Casing color
Internal Parts color
IP rating
Automation Made Easy
PRODUCT INFORMATION
Resistive Temp Sensor
TIS Infrared code receiver
2-3 Digital Inputs
3 Relay Output 3A/5A
12V DC 50mA Output
IR Emitter
Max. 64
12-32 V DC
<40 mA / 24 V DC
0.9 inch OLED Screen
For controlling lights, Air condition scene, etc...
10 Blue and Red LED + 1 Green LED
5
pairs of White neon LED
TIS Protocol messages and commands
1 X mini USB for up to date upgrading.
ON / OFF / Scene
Dim or ramp the lights
Extra Scene
Music, scene, lights control
90mm × 15mm × 125mm (21mm peak)
PC anti fire
Black, Titanium, Silver, White, Champaign, coal,
Bronze or special color
Black & White
IP 30
