INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
MONTPELIER II WOOD INSERT
MODEL NUMBER:
MONTP-II-CB
MONTP-II-BM
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
If the information in these instructions is not
followed exactly, a fire may result causing
property damage, personal injury, or death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over fire - If heater or chimney connector glows,
you are over firing. Over firing will void your warranty.
• Comply with all minimum clearances to combustibles
as specified.
• Failure to comply may cause house fire.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
• Do not touch glass until it is cooled
• Use leather gloves when reloading fuel
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as appliance.
• Alert children and adults to hazards of high temperatures
• High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate
poisonous gases (i.e. carbon monoxide).
NOTE: To obtain a French translation of this manual, please
contact your dealer or visit www.vermontcastings.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre revendeur ou
visitez www.vermontcastings.com
7101-802G
!
WARNING
!
WARNING
!
WARNING
07/20
Advertisement
Table of Contents
Related Manuals for Vermont Castings MONTPELIER II MONTP-II-CB
Summary of Contents for Vermont Castings MONTPELIER II MONTP-II-CB
- Page 1 Installation Manual Installation & Appliance Set-Up INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is not MONTPELIER II WOOD INSERT followed exactly, a fire may result causing property damage, personal injury, or death.
-
Page 2: Table Of Contents
M. Altering the Fireplace......17 N. Zero-Clearance Fireplace ....17 Vermont Castings is a registered trademark of Hearth & Home Technologies. 7101-802G... -
Page 3: Important Safety Information
Important Safety Information A. Insert Safety Certification C. BTU & Efficiency Specifications Model Number: MONTP-II-CB & MONTP-II-BM EPA Certification Number: 199-19 Number: Laboratory: OMNI Test Laboratories, Inc. EPA Certified Emissions: 1.9 grams per hour Report Number: 0061WN100S *LHV Tested Efficiency: 77.0% Type: Solid Fuel Type, Listed Room Heater **HHV Tested Efficiency: 71.3%... -
Page 4: Mobile Home Approved (Usa Only)
D. Mobile Home Approved (USA only) J. California - Prop65 • WARNING: DO NOT INSTALL IN A SLEEPING ROOM. WARNING • CAUTION: THE STRUCTURE INTEGRITY OF THE This product and the fuels used to operate this product (wood), and MOBILE HOME FLOOR, WALL, AND CEILING/ROOF the products of combustion of such fuels, can expose you to MUST BE MAINTAINED. -
Page 5: Getting Started
Getting Started A. Design and Installation Considerations NOTICE: Hearth & Home Technologies assumes no responsibility for the improper performance of the CAUTION appliance system caused by: • Inadequate draft due to environmental conditions • Down drafts Check building codes prior to installation. •... -
Page 6: Tools And Supplies Needed
E. Inspect Appliance and Components WARNING • Remove appliance and components from packaging and inspect for damage. Fire Risk. • Vent system components and doors are shipped in Hearth & Home Technologies disclaims any separate packages. responsibility for, and the warranty will be voided by, the following actions: •... -
Page 7: Install Checklist
F. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjuction with, not instead of, the instructions contained in this installation manual. _________________________________________________________________________________ Customer: ______________________________________________________________________________ Date Installed: ______________________________________________________________________________ Lot / Address: ________________________________________________________________________ Location of Appliance:... -
Page 8: Dimensions And Clearances
Dimensions and Clearances A. Dimensions NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) 31-1/2 in (801mm) 31-1/2 in (800mm) 23-5/8 in (602mm) 23-5/8 in (602mm) 17-7/8 in 17-7/8 in (455mm) (455mm) 2 in 2 in (50mm) (50mm) Figure 3.1 - Top View with Small Surround (SPVC-4331) Figure 3.4 - Top View with Large Surround (SPVC-5134) 43 in (1092mm) 51 in (1295mm) - Page 9 14 in (357mm) 31-1/2 in (800mm) 23-5/8 in (602mm) 25-3/8 in 17-5/8 in (645mm) (448mm) Figure 3.10 - Side View with Small or Large Surround (SPVC-4331 or SPVC-5134) and Optional 15 Degree Adapter 2-1/4 in (58mm) (DV-6DLR-E15ADSS) Figure 3.7 - Top View with Cast Surround (MED-CB or MED-BN) 13-3/4 in (349mm) 44 in (1118mm)
-
Page 10: Clearances To Combustibles
B. Clearances to Combustibles United States and Canada (UL and ULC) In Canada a full length 6 inch (152mm) S635 flue liner required as per ULC S628. In USA a minimum 5 ft length (1.82m), 6 inch (152mm) diameter flue liner is required as per UL 1482. TOP TRIM (3/4”... - Page 11 Material WARNING Thermal Resistance: R value The R value is a measure of a material’s resistance to Fire Risk. heat transfer. • Comply with all minimum clearances to R value is convenient when more than one material is used combustibles as specified. since you can add the R values together, whereas you can •...
-
Page 12: Chimney Systems
Chimney Systems A. Locating Your Stove & Chimney Location of the appliance and chimney will affect performance. As shown in Figure 4.1 the chimney should: • Install through the warm space enclosed by the building envelope. This helps to produce more draft, especially during lighting and die down of the fire. -
Page 13: Chimney Termination Requirements
B. Chimney Termination Requirements NOTICE: Locating the appliance in a basement or in Follow manufacturer’s instructions for clearance, securing a location of considerable air movement can cause flashing and terminating the chimney (Figure 13.1 & intermittent smoke spillage from appliance. Do not locate appliance near. -
Page 14: Venting Systems
D. Venting Systems WARNING Chimney Connector: Asphyxiation Risk. It is also known as flue pipe or stove pipe. It must be 6 inches (152mm) minimum diameter stainless steel connector pipe. • DO NOT CONNECT THIS Appliance TO A CHIMNEY FLUE SERVICING Chimney: ANOTHER APPLIANCE. -
Page 15: Larger Chimneys
H. Larger Chimneys • Cross-sectional area shall conform to NFPA 211-2006 Section 12.4.5.1. It is recommended that chimneys with larger diameters than • Should be lined with a 6 inch (152mm) stainless steel flue 6 inches (152mm) be relined. An oversized flue can affect liner to improve performance and reduce creosote build- draft and impair performance and will allow increased build- up of creosote. -
Page 16: Metal Heat Circulating Masonry
J. Metal Heat Circulating Masonry • The air flow of the factory-built zero-clearance fireplace system must not be altered. The flue liner top support This insert conforms with the safety standard UL-1482 and attachment must not reduce the air flow for the existing ULC S628 (Canada) in all respects and is approved to UL air-cooled chimney system. -
Page 17: Ovalizing Round Stainless Steel Liners
L. Ovalizing Round Stainless Steel Liners N. Zero-Clearance Fireplace Ovalizing round stainless steel liners to accommodate the A permit may be required for installations, final approval is liner passing through the damper region of a fireplace is an contingent of the authority having local jurisdiction. Consult allowable and acceptable practice. -
Page 18: Appliance Set-Up
Appliance Set-Up A. Outside Air Kit A source of air (oxygen) is necessary in order for combustion to take place. Whatever combustion air is consumed by the fire must be replaced. Air is replaced via air leakage around windows and under doors. In homes that have tightly sealed doors and windows, an outside air source is needed. -
Page 19: Securing Stove Pipe/Liner To Flue Collar
Part Number 4615 may be purchased directly through your local Simpson Duravent Pipe Distributor or from your local 5/16 Bolts Vermont Castings dealer, Part Number DV-6DLR-E15ADSS. Figure 5.4 shows a vertical installation and also how to create an optional 30° elbow installation. -
Page 20: Flat Surround
E. Flat Surround Overall Dimensions Part Number Standard Size 43” x 31” SPVC-4331 Large Size 51” x 34” SPVC-5134 Table 5.1 1. Lift surround to front of appliance (Figure 5.6) Trim Kit Option Top: over lip on top of Flat appliance Surround Figure 5.8... -
Page 21: Cast Surround Assembly
F. Cast Surround Assembly NOTE: Due to variances in cast manufacturing, it may be required to add a 1/4 inch SAE washer to the surround Overall Part Number Color assembly between the securing brackets and the Dimensions mounting location (Figure 5.13). MED-CB Classic Black 44”... -
Page 22: Power Cord
H. Power Cord The power cord is shipped in the component pack of the appliance. You may route the power cord either to the left or right side depending on your configuration for power source (Figure 5.17). Figure 5.15 Panel Extension Assembly to Cast Surround Assembly NOTE: Reference Cast Surround Assembly on how to assemble cast surround set. -
Page 23: Mobile Home Installation
Mobile Home Installation, Approved for USA Installation only! You must use a Vermont Castings Outside Air Kit Spark Arestor Cap Part number: OAK-ACC 1. An outside air inlet must be provided for combustion and must remain clear of leaves, debris, ice and/or snow. It... -
Page 24: Reference Materials
Reference Materials A. Service and Maintenance Log Date of Service Performed By Description of Service 7101-802G 07/20... - Page 25 Date of Service Performed By Description of Service 7101-802G 07/20...
-
Page 26: Accessory List
IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide B. Accessory List model number and serial number when requesting service parts from your dealer or distributor. at Depot ITEM DESCRIPTION... - Page 27 Montpelier II Service Parts Beginning Manufacturing Date: Aug 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Hearth and Home Technologies does not sell directly to consumers distributor. . Provide Stocked at model number and serial number when requesting service parts from your dealer or distributor.
- Page 28 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Vermont Castings dealer with any questions or concerns. For the number of your nearest Vermont Castings dealer log onto www.vermontcastings.com CAUTION DO NOT DISCARD THIS MANUAL •...
