Installation and Appliance Setup - Care and Operation
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Call your dealer for questions on Installation, Operation, or Service.
NOTICE: SAVE THESE INSTRUCTIONS
Montpelier Medium Insert
For Use in North America
1
Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18
Owner's Manual
SAFETY NOTICE: IF THIS APPLIANCE IS NOT
P R O P E R LY I N S TA L L E D , O P E R AT E D A N D
MAINTAINED, A HOUSE FIRE MAY RESULT.
TO REDUCE THE RISK OF FIRE, FOLLOW THE
INSTALLATION INSTRUCTIONS. FAILURE TO
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY
DAMAGE, BODILY INJURY OR EVEN DEATH.
CONTACT LOCAL BUILDING OFFICIALS ABOUT
RESTRICTIONS AND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
!
Please read this entire manual before
installation and use of this wood-burning
room heater.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
!
WARNING
CAUTION
3-90-30004403
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vermont Castings Montpelier Medium Insert
Summary of Contents for Vermont Castings Montpelier Medium Insert
- Page 1 Failure to follow these instructions could result in property damage, bodily injury or even death. For Use in North America CAUTION Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
-
Page 2: California Safety Information
TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH. CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA. Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... -
Page 3: Electrical Rating
EPA emission test. Blower Rating Power Cord Lenght during EPA emission test. and the burn rates from the low and high EPA tests, using Douglas Fir dimensional lumber. Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... - Page 4 11-1/2” (292 mm) 21-9/16” (547 mm) 30-1/2” (774 mm) 17-1/4” (434 mm) 28-3/4” (730 mm) 22-1/4” (565 mm) 21-1/2” (548 mm) 21-9/16” (547 mm) Figure 1 - Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
-
Page 5: Installation
Requirements for Existing Chimneys General Considerations / U.S. Chimney Height / U.S. and Canada DO NOT CONNECT YOUR MONTPELIER MEDIUM INSERT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... - Page 6 Minimum Fireplace Dimensions NOTE: Sealing Requirements / U.S. Canada In Canada (CAN/CSA-B365-M91, Section 5), if installed Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
- Page 7 Fireplace Minimums 3" Extended Flush Mount Mount Fireplace Maximums Figure 4 Figure 3 Clearance Requirements Hearth Requirements How to Determine if Alternate Floor Protection Materials are Acceptable Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
- Page 8 EXAMPLE: total Canada United States total R-value of 1.49 Optional Surround Packages Figure 5 Georgian Cast Surround Enclosure Area Mead Cast Surround: Procedure: Steel Surround: Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
- Page 9 Route the blower power cord. NOTE: DO NOT RUN THE POWER CORD UNDER OR IN FRONT OF THE UNIT. Install the Optional Surround Kit. Roll the Firebox into Position. Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
- Page 10 • • • Safety Tips Connect the Blower power cord to the power supply. DO NOT ROUTE THE POWER CORD UNDER OR IN FRONT OF THE UNIT. Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
-
Page 11: Operation
Open - Control Lever to the Left Closed - Control Lever to the Right Figure 9 The Fans Figure 8 Primary Air Control The primary air control lever WARNING Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... - Page 12 Insert, and burn it directly on the grate. Do not elevate Use the Air Control Settings that Work Best for You the fuel. Do not burn coal or other fuels. Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
- Page 13 Push coals away from the three bottom air jets. Creating this “void” NOTE: HOT WHILE IN OPERATION! KEEP CHILDREN, CLOTHING, AND FURNITURE AWAY. CONTACT MAY CAUSE SKIN BURNS. Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
- Page 14 Remove and Store Ash Safely Andiron CAUTION Figure 11 NOTE: Special Tactics for Cold-Climate Heating Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
-
Page 15: Maintenance
Adjust the Door Latch Periodically Working Its BestCare of the Cast Iron Surface Care of the Porcelain Enamel Surface Small Locking Nut Large Locking Nut Cleaning the Glass Figure 12 Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... -
Page 16: Important Notes
IMPORTANT NOTES • • • How to Replace Gaskets Removing and Replacing Door Glass Replaceable Montpelier Medium Insert Fiberglass Gaskets Figure 13 - Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... -
Page 17: The Chimney System
Replacing the Door Gaskets The Chimney System A Clean Chimney System is Safer and Works Better Learn to Recognize and Avoid Creosote Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... -
Page 18: Optional Accessories
Model Color Mead Cast Surround Model Color Trim Kit Base Risers (for use with most surrounds) Model Model Color Note: Steel Surround Model Color Extended Trim Plate Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... -
Page 19: Service Parts List
Service Parts List Montpelier Medium Insert Ref. Description Part Number Ref. Description Part Number Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... - Page 20 Montpelier Medium Insert (continued) Ref. Description Part Number Ref. Description Part Number NOTES: Shell Enamel Parts - Montpelier Medium Insert Part Name Classic Black Brown Majolica Front Door Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
-
Page 21: Limited Lifetime Warranty
Firebox and heat exchanger, Grate and Stainless Limited Steel Burners, FlexBurn System (engine, inner 3 years Lifetime cover,access cover and fireback) 90 Days All replacement parts beyond warranty period Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... -
Page 22: Warranty Conditions
WARRANTY CONDITIONS: other than the dealer from whom you originally purchased the product. • Limited Catalyst Warranty Amount of Time Since Purchase Credit Towards Replacement Cost WARRANTY EXCLUSIONS: Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... -
Page 23: Limitations Of Liability
• There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited LIMITATIONS OF LIABILITY Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403... - Page 24 Vermont Castings • Montpelier Medium Insert Installation & Operating Manual_R23 • 11/18 3-90-30004403...
