Voice Display

Four LEDs below the VALUE encoder display the currently active
voices. Voices 1 to 4 are visualized red, voices 5 to 8 in green.
PRESETS – Selection and Storing
SYNTH PRO offers 240 preset locations. To select, press the PRESET
button. The lowermost display-row shows the current preset 1 to 8
and the bank 01 to 30. Use the VALUE encoder to select a bank.
Subsequently, use the MISC buttons 1 to 8 to call up a preset in that
bank. In doing so, the synthesizer will return back to play-mode.
Pressing the PRESET button instead of buttons 1 to 8 instead, SYNTH
PRO will adapt all current settings of the controls and switches. The
bank selection will remain as is. This function makes programming
new presets easier.
To save a preset, press STORE first. In doing so, the two LEDs above
the button will be lit red/green. Next press the PRESET button (LED lit
red), select a bank using the VALUE control and a press one of the
MISC buttons 1 to 8. The preset is now saved and SYNTH PRO returns
back to play-mode. The LED above PRESET will turn off.
Hint: To avoid possible voice assignment issues or hanging notes, do
not run the internal sequencer or arpeggiator while loading or
saving presets. Also avoid sending MIDI-notes to the MIDI-input.

MENU Voice Mode

The eight voices of SYNTH PRO can be assigned or divided in
different ways. MENU Voice Mode is the first menu. It will be
displayed after switching the device on. It can also be selected by
turning the MENU encoder.
Type: Poly > Poly1+7 > Chord+4 > Mono > Unisono > Rotate
DTune: 00-15 or Legato Off/On (Mono) olso for Poly1+7 and Unisono
Active Voice: 01-08 (display only)
