Transpose; Midi-Settings; Data-Transfer - MFB SYNTH PRO Operating Manual

By pressing the MISC button TEMPO (8) – the corresponding LED will
be lit red – the lowermost display-row changes to a tempo-
indication. It can be adjusted between 040 and 239 (BPM) using the
VALUE control. Exit the tempo-menu by pressing TEMPO (8) again –
the corresponding LED turns off. The display setting remains visible
until a different MISC function is called up.
By pressing the MISC button SHUFFLE (5) – the corresponding LED will
be lit red – the lowermost display-row changes to a shuffle indication
which can be adjusted between 00 and 09 using the VALUE control.
A value of 00 means that the shuffle-function is inactive. Leave the
shuffle-menu after carrying out your adjustments by pressing the
same button – the corresponding LED will turn off. The display setting
remains visible until a different MISC function is called up.
Hint: It is recommended to stop the sequencer when changing the
shuffle-settings, because synchronization may else be lost.

Transpose

An arpeggio with the hold-function being enabled can be
transposed freely using the keys of a connected MIDI-keyboard.

MIDI-SETTINGS

The MENU MIDI allows adjustments for the send- and receive-
channel, clock and controllers.
Channel: 01-16
Clock: Int, Ext
CChg/PChg: Off, Send, Receive (sending and receiving controller
data at the same time is not possible)

DATA-TRANSFER

Presets, sequences and voice-updates can be transmitted or
exchanged with a computer using the USB PC port. This is done from
the MENU USB Transfer. In addition, newer firmware versions can be
loaded into SYNTH PRO. (Find the corresponding manuals on the
MFB-website)
Preset: Off, Send, Receive
Sequence: Off, Send, Receive
Update: Off, Voices
20
