Operation

All sound shaping functions of SYNTH PRO can be adjusted using
dedicated control elements. Parameters and values currently being
changed will be displayed in the topmost display-row.
Additional functions for each section, such as modulation routings,
are available via menus which are selected using the display and
the MENU encoder. Each menu offers (up to) three sub-entries,
which are selected by pressing the VALUE encoder consecutively.
The selected parameter changes in color from red to green and
can be adjusted using the VALUE encoder.
The display shows parameters in six rows.
1 – the function last used: value
2 – selected menu
3 – menu-parameter 1: value
4 – menu-parameter 2: value
5 – menu-parameter 3: value
6 – varying notifications – preset, bank, FM select, MISC-functions

Oscilloscope

By pressing the MENU encoder, the display changes to a real-time
waveform-display.
Below the waveform, trigger and timing-values can be adjusted.
Return to the regular display-menu by pressing the encoder again.
