Metro DataVac STARSYS Instructions For Use Manual

Mobile power cart
Hide thumbs Also See for STARSYS:

Advertisement

Quick Links

L01-491, Rev.A
10/2012
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
For Product Information Call: 1-800-992-1776,
Visit Our Web Site: www.metro.com
STARSYS MOBILE
POWER CART
INSTRUCTIONS
FOR USE
THIS MANUAL COVERS CARTS WITH
ELECTRICAL RATINGS OF: 12V, 19V & 24V
Metro Mobile Power Carts are for
Health Care applications only

Advertisement

loading
Need help?

Need help?

Do you have a question about the STARSYS and is the answer not in the manual?

Questions and answers

Related Manuals for Metro DataVac STARSYS

Summary of Contents for Metro DataVac STARSYS

  • Page 1 STARSYS MOBILE POWER CART INSTRUCTIONS FOR USE THIS MANUAL COVERS CARTS WITH ELECTRICAL RATINGS OF: 12V, 19V & 24V Metro Mobile Power Carts are for L01-491, Rev.A Health Care applications only 10/2012 InterMetro Industries Corporation North Washington Street, Wilkes-Barre, PA 18705 For Product Information Call: 1-800-992-1776, Visit Our Web Site: www.metro.com...

  • Page 2: Table Of Contents

    For all service items, please contact InterMetro Customer Service. CAUTION: Do not operate the Starsys cart, if it has received a severe impact or has been otherwise physically damaged. Please have a qualified service person inspect both the Starsys cart in conjunction with its power supply for any performance or safety hazard prior to putting back into service.

  • Page 3: Introduction

    Cart Overview and Features Starsys Mobile Power Cart provides a complete management of power which is supplied to the cart and its accessories. • The power supply is a rechargeable power source which is located in the bottom of the cart. The electrical cables and connectors from power supply pass through guided path inside the cart body and up to the All-in-one computer/monitor.

  • Page 4: Getting Started With Cart

    Unpacking The Starsys Mobile Power cart will arrive fully assembled and fully functional at the customer’s site (most accessories do not ship assembled to the cart. After cutting the strapping bands, lift the top of the box over the cart. In order to avoid any injury, two (2) people should lift the cart from the padding blocks.
  • Page 5 5. At each connector, firmly grip the cable plug between thumb and index finger. Line up the plug with the socket below it and insert it downward all the way until the latch locks completely. The latch should click into place as shown in Figure 6.
  • Page 6 ON into the “ON” position which is located on the side of power supply as shown in Figure 9. In the “ON” position, the power supply provides power to the Starsys Mobile Power Cart. If the cart is not being used for an extended period of time, the ON should be put in the OFF position.

  • Page 7: Operation Of Mobile Power Cart

    OPERATION OF MOBILE POWER CART Description of Major Components Depending on your order, your Starsys Mobile Power Cart will be delivered in a specific configuration. The configuration may employ the following major components: • Power Supply • Lockalert Touchpad • Fuel Gauge •...
  • Page 8 All-In-One computer/monitors. Refer to Figure 12. • Powering Up the Monitor: The Starsys Cart power supply must be turned ON first before turning ON the monitor. The ON/OFF switch for monitor is located at the back of monitor and can be turned ON/OFF as required.
  • Page 9 Monitor Mounting All-In-One Bracket Computer/ Monitor Overbridge Monitor Rail Wire Clip 14: M igure onitor ounteD on VerbriDge All-In-One Computer/ Monitor Vesa Plate Articulating Arm 15: M igure onitor ounteD on rtiCulating...
  • Page 10 17” 11.81” MOUNTING (431.8mm) LOCATION OF (284.2mm) MONITOR RAIL ON OVERBRIDGE 1.68” (42.9mm) 60” (1524mm) 20.81” (528.62mm) 16: o igure VerbriDge anD onitor ount eights Power Cord REFER TO SECTION “Replacement Parts List” FOR VARIOUS POWER Clamp CORD OPTIONS Screw Power Cord Note: Disconnect power cord from AC power source 1.

  • Page 11: Maintenance & Replacement Parts Lists

    MAINTENANCE & REPLACEMENT PARTS LISTS Cleaning Instructions Use 70 percent isopropyl alcohol (IPA) diluted with water for cleaning power supply. You may also use one of these products to clean the power supply: • Cidex • Clorox Clean-Up • “Green soap” United States Pharmacopoeia (USP) •...
  • Page 12 Replacement Parts List Certain replacement parts are based on voltage or monitor/computer type. Please confirm desired voltage and monitor/computer type when ordering parts. ITEM# PART DESCRIPTION RPSXR402198 Power Supply RPSXRC13-743 DC Power Cable, 5.5mm x 2.5mm x 42” LG (1067mm) RPSXRC13-744 DC Power Cable, 5.5mm x 2.1mm x 42”...
  • Page 13 Keyboard Tray 24" 42" 60" 42" VIEW-B 24" 60" 60" VIEW-A 17: r igure ePlaCeMent arts heet...
  • Page 14 To Fuel Gauge To Computer To Computer 24" 42" 60" 60" To LA6 60" 36" 96" 10" EXPLODED VIEW OF POWER SUPPLY CABLES 18: r igure ePlaCeMent arts heet...

  • Page 15: Wiring Diagram

    WIRING DIAGRAM...

  • Page 16: Basic Troubleshooting

    BASIC TROUBLESHOOTING Power Supply Overheating, AC-DC Module / DC-DC Module: • Air flow in the power supply may be restricted due to cooling fan not working properly, fan blocked, or clogged ventilation slots around the power supply case. • Turn off computer equipment and then the power supply. •...
