QUICK START GUIDE
STARSYS
®

BASIC TOUCHPADS

Touchpads for Basic Models:
1. Proximity Card Reader scan area (If equipped)
2. Replace battery indicator (yellow LED)
3. Access Denied indicator (red LED)
4. Unlocked Cart indicator (green LED)
5. Numeric keypad
6. "LOCK/CLEAR" button
7. "ENTER" button
Carts arrive with 2 pre-programmed codes. The following is a review of each:
• The default supervisor code is 1350. Supervisor credentials unlock the cart and can add or delete users and other supervisors.
• The default user code is 0531. User credentials can only unlock the cart.

Unlocking the Cart using the Touchpad or the Card Reader:

PIN CREDENTIAL

:
1. Enter a valid PIN (between 4 - 14 digits).
2. Press "ENTER."
• If the code is VALID, system will automatically unlock unit.
• If the code is INVALID, system will not unlock unit (red LED indicator on keypad (callout 5) will blink 3 times and 3 beeps will be
heard). Re-enter correct code.
• If enabled, the Bad Credential Lockout mode will be triggered if a certain number of INVALID CODES are entered within a set
number of minutes. If the Bad Credential Lockout mode is activated, the unit will lock out the touchpad for a set number of
minutes, and no access will be granted via the touchpad until the timeout has expired. The settings for the Bad Credential
Lockout are accessed via the LockView software.
CARTS WITH KEYLESS ENTRY
2
4 3
5
Basic Touchpad
6 7
1
