Metro DataVac STARSYS Quick Start Manual

ADVANCED / WIRELESS - QUICK START GUIDE
STARSYS

ADVANCED / WIRELESS Keypad

1. Dot matrix LCD
2. Network button (blue LED)
3. "UP" button
4. "NEXT/SELECT" button
5. "BACK/CANCEL" button
6. "MENU" button
7. "DOWN" button
8. + Button
9. - Button
10. Low battery indicator (yellow LED)
11. Magstripe reader location (if equipped)
12. Proximity Card Reader scan area
13. "ENTER" button
14. "CLEAR" button
15. Alpha-numeric keypad
Carts arrive with 2 pre-programmed codes. The following is a review of each:
• The default supervisor code is 1350. Supervisor credentials unlock the cart and can add or delete users and other supervisors.
• The default user code is 0531. User credentials can only unlock the cart.

Unlocking the Cart using the Keypad or the Card Reader:

PIN CREDENTIAL:

1. Enter a valid PIN (between 4 - 14 digits).
2. Press "ENTER."
3. If the code is VALID, system will automatically unlock unit.
4. If enabled, the Bad Credential Lockout mode will be triggered if a certain number of INVALID CODES are entered within a set
number of minutes. If the Bad Credential Lockout mode is activated, the unit will lock out the Keypad for a set number of minutes,
and no access will be granted via the Keypad until the timeout has expired. The settings for the Bad Credential Lockout are
accessed via the LockView software.
PROXIMITY ADVANCE LOCKING
®
1
2
3
4
5
6
7 8
9
10
15
14
13
12
11
