Do you have a question about the TC Series and is the answer not in the manual?
Questions and answers
valmeron Martins
February 26, 2025
sim no manual não tem a sequencia correta de instalar
1 comments:
Mr. Anderson
February 26, 2025
The Autonics TC Series temperature controller should be installed as follows:
1. Mounting: Choose a suitable panel or DIN rail for installation. Ensure the mounting space accommodates the compact size of the device. 2. Wiring: Connect the power supply according to the model specifications: - 24VAC 50/60Hz, 24-48VDC (for models with power supply option "2"). - 100-240VAC 50/60Hz (for models with power supply option "4"). 3. Control Output Connection: Depending on the model, connect either: - Relay output. - SSR drive output for phase control or cycle control. 4. Alarm Output (if applicable): Connect alarm outputs if the model includes one or two alarm functions. 5. Sensor Connection: Attach the appropriate temperature sensor to the input terminals. 6. Configuration: Use the touch switch interface to set the desired parameters, including temperature setpoints and control modes. 7. Verification: Power on the device and verify that the PV (Process Value) and SV (Set Value) display correctly. 8. Testing: Perform an auto-tuning operation if necessary to optimize PID control.
Ensure wiring is done correctly to avoid malfunctions, and follow safety precautions during installation.
This answer is automatically generated
valmeron Martins
February 26, 2025
preciso fazer a instalação do Tc4-M, mas no manual não msotra a sequencia de entrada de energia e saida para a resistência e onde entra o cabos do termostto
1 comments:
Mr. Anderson
February 26, 2025
To install the Autonics TC4-M temperature controller, follow these steps:
1. Panel Mounting - Cut a hole in the panel according to the TC4-M dimensions (W96×H96mm). - Insert the controller into the panel cutout. - Secure the unit using the provided bracket by pushing it with tools.
2. Power Input Connection - Connect the power supply to the designated terminals. - For AC power: Use 100-240VAC 50/60Hz. - For AC/DC power: Use 24VAC 50/60Hz or 24-48VDC. - Ensure the voltage is within the allowable range (90-110% of rated voltage).
3. Sensor (Thermocouple/RTD) Connection - Connect the thermocouple (K, J, or L type) or RTD (Pt100Ω, Cu50Ω) to the appropriate input terminals. - Ensure proper polarity and wiring to avoid measurement errors.
4. Heater Output Connection - If using relay output: Connect the heater to the relay output terminals (250VAC, 3A max). - If using SSR drive output: Connect the SSR to the SSR output terminals, considering the control method (ON/OFF, cycle, phase control).
5. Alarm Output (Optional) - If using alarm output, connect the alarm device to the designated relay output terminals (250VAC, 1A max).
6. Final Checks and Power On - Verify all connections are secure. - Power on the controller and configure the settings using the touch switch. - Set the temperature parameters and confirm proper operation.
Ensure that the connections follow the correct wiring diagram for the TC4-M model.
Need help?
Do you have a question about the TC Series and is the answer not in the manual?
Questions and answers
sim no manual não tem a sequencia correta de instalar
The Autonics TC Series temperature controller should be installed as follows:
1. Mounting: Choose a suitable panel or DIN rail for installation. Ensure the mounting space accommodates the compact size of the device.
2. Wiring: Connect the power supply according to the model specifications:
- 24VAC 50/60Hz, 24-48VDC (for models with power supply option "2").
- 100-240VAC 50/60Hz (for models with power supply option "4").
3. Control Output Connection: Depending on the model, connect either:
- Relay output.
- SSR drive output for phase control or cycle control.
4. Alarm Output (if applicable): Connect alarm outputs if the model includes one or two alarm functions.
5. Sensor Connection: Attach the appropriate temperature sensor to the input terminals.
6. Configuration: Use the touch switch interface to set the desired parameters, including temperature setpoints and control modes.
7. Verification: Power on the device and verify that the PV (Process Value) and SV (Set Value) display correctly.
8. Testing: Perform an auto-tuning operation if necessary to optimize PID control.
Ensure wiring is done correctly to avoid malfunctions, and follow safety precautions during installation.
This answer is automatically generated
preciso fazer a instalação do Tc4-M, mas no manual não msotra a sequencia de entrada de energia e saida para a resistência e onde entra o cabos do termostto
To install the Autonics TC4-M temperature controller, follow these steps:
1. Panel Mounting
- Cut a hole in the panel according to the TC4-M dimensions (W96×H96mm).
- Insert the controller into the panel cutout.
- Secure the unit using the provided bracket by pushing it with tools.
2. Power Input Connection
- Connect the power supply to the designated terminals.
- For AC power: Use 100-240VAC 50/60Hz.
- For AC/DC power: Use 24VAC 50/60Hz or 24-48VDC.
- Ensure the voltage is within the allowable range (90-110% of rated voltage).
3. Sensor (Thermocouple/RTD) Connection
- Connect the thermocouple (K, J, or L type) or RTD (Pt100Ω, Cu50Ω) to the appropriate input terminals.
- Ensure proper polarity and wiring to avoid measurement errors.
4. Heater Output Connection
- If using relay output: Connect the heater to the relay output terminals (250VAC, 3A max).
- If using SSR drive output: Connect the SSR to the SSR output terminals, considering the control method (ON/OFF, cycle, phase control).
5. Alarm Output (Optional)
- If using alarm output, connect the alarm device to the designated relay output terminals (250VAC, 1A max).
6. Final Checks and Power On
- Verify all connections are secure.
- Power on the controller and configure the settings using the touch switch.
- Set the temperature parameters and confirm proper operation.
Ensure that the connections follow the correct wiring diagram for the TC4-M model.
This answer is automatically generated
