This manual contains information on limitations regarding product use and
function and information on the limitations as to liability of the manufacturer.
The entire manual should be carefully read.
PC151O
• W A R N I N G •
Software Version 4.1
DLS-1 V6.5 and up
Installation
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC1510 and is the answer not in the manual?

Questions and answers

Related Manuals for DSC PC1510

Summary of Contents for DSC PC1510

  • Page 1 Installation Manual Software Version 4.1 PC151O DLS-1 V6.5 and up • W A R N I N G • This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.
  • Page 2 100. indices de charge de l’ensemble des dispositifs ne dépasse pas 100. The Load Number of this unit is 2. L’Indice de charge de ce produit est 2. This manual is for the PC1510 software version 4.1...
  • Page 3 TABLE OF C ONTENTS FEATURES SPECIFICATIONS INSTALLATION Mounting the Panel ................................2 Mounting the Keypad ............................... 2 Auxiliary Power Connection .............................. 2 PGM Terminal Connections .............................. 2 Bell/Siren Connection ................................ 2 Keypad Wiring .................................. 2 Fire Zone Wiring ................................3 Burglary Zone Wiring ................................

  • Page 4: Table Of Contents

    PROGRAMMING GUIDE Introduction ..................................10 Programming .................................. 10 Program Data Review ..............................10 Binary Data Display ................................ 10 HEX Data Programming ..............................10 PROGRAMMING SECTIONS [00] Binary Programming ............................... 11 [01] 1st Phone Number ..............................11 [02] 1st Account Code ..............................11 [03] 2nd Phone Number ..............................
  • Page 5 FEATURES SPECIFICATIONS Keypad Programmable PC1510 Control Panel The PC1510 is complete with a default program so that it is • Six fully programmable zones operational with a minimum of programming. The control - EOL resistor (±30% EOL) supervised option panel is completely programmable from the keypad.
  • Page 6 INSTALLATION Mounting the Panel Bell/Siren Connection Select a dry location close to an unswitched AC source and 12VDC close to the telephone line connection. Remove the printed FUSE circuit board, the mounting hardware and the keypad from the cardboard retainer inside the cabinet. Before attaching BELL the cabinet to the wall, press the four white nylon printed circuit board mounting studs into the cabinet from the back.
  • Page 7 The wiring table gives the wire run length from the control panel Fire Zone Power Wiring Chart to the keypad for various gauges of wire. Wire run lengths are Max. Wire Run to E.O.L. Relay based on the maximum current drawn by the keypad. (All lights Current ON).
  • Page 8 If the battery charging voltage is out of adjustment, contact your service representative. NOTE: The PC1510 will not power up, even with a fully charged battery, until AC power is connected. After an extended AC power failure, the battery will be automatically disconnected when its voltage drops to between 9 V and 10 V.
  • Page 9 GUIDELINES FOR LOCATING SMOKE DETECTORS Experience has shown that all hostile fires in family living units generate smoke to a greater or lesser extent. Experiments using typical fires in family living units indicate that detectable quantities of smoke precede detectable levels of heat in most cases.
  • Page 10 If a correct access code is entered, and you do not exit the premises, the system will, at the end of the exit delay time, and control of the PC1510 control panel. The panel can be fully arm with interior zones automatically bypassed if those programmed from the keypad.
  • Page 11 Definitions section [11] for fire loop zone assignment. Enter [zone number to be bypassed]; the zone light will come 6. Loss of Time on System Clock When the PC1510 is ON to indicate that the zone is bypassed. To remove a powered up or reset, the internal time of day clock needs bypass, enter the zone number and the zone light will go OFF.
  • Page 12 Set Auto-Arm Time ∗ ∗ ∗ ∗ ∗ [#] key to exit this section. ]+[6]+[Master Code]+[2] The PC1510 can be programmed to arm at the same time Erasing a Code ∗ each day. At the selected Auto-Arm time, the bell will sound To erase a code, enter [ ][5][Master Code].
  • Page 13 The keypad will ∗ ∗ ∗ ∗ ∗ ]+[8]+[Installer’s Code] sound a series of short beeps once the panel has accepted The PC1510 is completely programmed from the keypad by the alarm. ∗ using commands in the [ ][8] section.

  • Page 14: Programming Guide

    PROGRAMMING GUIDE Introduction Program Data Review The PC1510 is fully programmable from the keypad and uses an • Enter the section you wish to program by entering the 2- EEPROM memory which can be reprogrammed thousands of digit section number.

  • Page 15: Programming Sections

    PROGRAMMING SECTIONS [00] Binary Programming 2-digit entry. After the last 2-digit number is entered, programming of the current section is complete. The keypad gives a series of This section is normally used upon instruction from factory beeps, the “Ready” light goes OFF and the “Armed” light comes technical personnel for specialized programming not covered ON.

  • Page 16: [07] Closing (Arming) Reporting Codes

    Transmission for operation of the [F], [A] and [P] keys will only [07] Closing (Arming) Reporting Codes take place if the appropriate sections in [09] are programmed Partial Closing Reporting Code with a reporting code. Reporting codes 1 to 6 are used to identify closings for access [10] Maintenance Alarms and Restorals codes 1 to 6.

  • Page 17: 1St System Option Code

    [2] Interior Loop is normally used with interior motion detectors 0.5 sec. ON, 0.5 sec. OFF, and has the standard exit delay time. The loop also has the 0.5 sec. ON, 0.5 sec. OFF, standard entry delay time provided that a delay loop has 0.5 sec.
  • Page 18 [13] 2nd System Option Code [15] Communication Variables Use the same method of programming as section [12]. Once this section is entered, two 2-digit numbers are expected. Do not press the [#] key while entering data. The first 2-digit ZONE number defines the number of attempts (alarm and restoral LIGHT pairs) per zone that the communicator will make before it shuts...
  • Page 19 [18] Auxiliary Delay Loop [23] Communication Formats Entry/Exit Times This section sets the type of format which will be sent to each of the two telephone numbers programmed in section [01] This section requires two 3-digit entries to establish the Auxiliary and [03].
  • Page 20 (i.e. Zone 1 = 10, Zone 2 = 20... Zone 6 = 60). The zero [05] Courtesy Pulse in the 2nd digit position tells the PC1510 not to send an This option provides an output which follows the entry extended round.
  • Page 21 [25] Communicator Call Directions Hardware If the installer’s code is forgotten and a software reset cannot be This section requires four single digit entries using digits 0 to 3 performed, the panel can be reset to the factory default values only.
  • Page 22 [35] For Future Use 1 transition of a delay zone) This Section is not used by the PC1510 Version 4.1 Software; • OFF = Quick-Exit is disabled do not program this section. ON = Auxiliary delay loops can be force armed •...
  • Page 23 PC1510 Version 4.1 FOR THE RECORD Customer ___________________________________________________________________________________________________ Address ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ Phone ___________________________________________ Installation Date _____________________________________ CONTACTS: #1 Name ___________________________________________ Phone ______________________________________________ #2 Name ___________________________________________ Phone ______________________________________________ #3 Name ___________________________________________ Phone ______________________________________________ Installer’s Code ______________________________________ ZONES Zone Type Protected Area...
  • Page 24 PC1510 Version 4.1 PROGRAMMING WORK SHEETS NOTE: In sections [01] to [10], do not enter data into sections that are not used. [01] 1st Phone Number Page 11 ∗ ∗ Enter [0] for the digit 0 in the phone number. Enter [ ] (HEX D) for additional dial tone detection between number digits, as in local PBX systems.
  • Page 25 PC1510 Version 4.1 [07] Closing (Arming) Reporting Codes / Partial Closing Reporting Code Page 12 Access Code 1 Access Code 2 Access Code 3 Access Code 4 Access Code 5 Access Code 6 Partial Closing Code [08] Opening (Disarming) Reporting Codes / After Alarm Reporting Code Page 12 The “after alarm”...
  • Page 26 PC1510 Version 4.1 [10] Maintenance Alarms and Restorals Page 12 For automatic test code reporting, time between reports (in days) must be specified in Section [17], and time of day for the report must be entered in Section [19]. Low Battery Alarm...

  • Page 27: 2Nd System Option Code

    PC1510 Version 4.1 [13] 2nd System Option Code Page 14 Default Zone Light ON Zone Light OFF 1 1 1 1 1 Zone Light 1 Call 1st phone only Backup to 2nd phone Zone Light 2 Master Code not changeable...

  • Page 28: Zone Bypass Mask

    PC1510 Version 4.1 [16] Zone Bypass Mask Page 14 ∗ If the zone light is ON, the zone can be bypassed using the [ ][1] command. If a zone is defined as a fire zone, it cannot be bypassed. Default...

  • Page 29: New Installer's Code

    PC1510 Version 4.1 [20] New Installer’s Code Page 15 ∗ For Sections [20], [21] and [22]: Enter 4 digits from “0” to “9”. Do not enter [ ] or [#]. Default 1 5 0 0 [21] New Master Code Page 15...

  • Page 30: Programmable Output Options (Pgm Terminal)

    PC1510 Version 4.1 [24] Programmable Output Options (PGM Terminal) Page 16 Enter 2 digits from “01” to “0C” only. Default Programmable Output [01] Ground Start Pulse ∗ [02] Utility Output, No Access Code - 5 seconds [ ] [7] ∗...

  • Page 31: Number Of Rings Before Answering

    PC1510 Version 4.1 [29] Number of Rings Before Answering Page 17 Enter a number from 01 to 12 to set the number of rings before the panel will answer. Default [30] Reset To Factory Default Page 17 [31] 4th System Option Code...

  • Page 32: 6Th System Option Code

    Enter 2 2-digit numbers in the range of 00 to 99. Program the Number of Invalid Codes as “00” to disable the lockout feature. [90] Installer’s Lockout Enable Page 18 [91] Installer’s Lockout Disable Page 18 WARNING! Panels returned to DSC with the Installer’s Lockout enabled and no other apparent problems will be subject to an additional service charge!
  • Page 33 HOOK-UP DIAGRAM WARNING For continued protection against the risk of fire, replace only with the same type and rating of fuse. INCORRECT CONNECTIONS MAY RESULT IN FUSE FAILURE OR IMPROPER OPERATION. INSPECT WIRING AND ENSURE CONNECTIONS ARE CORRECT BEFORE APPLYING POWER. 12V 4Ah SEALED BATTERY...
  • Page 34 I n s t a l l e r ’ s L o c k o u t Any products returned to DSC which have the Installer’s Lockout option enabled and exhibit no other problems will be subject to a service charge.
  • Page 35 WARNING Please Read Carefully N o t e t o I n s t a l l e r s This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warning to the attention of the users of this system.
  • Page 36 © 1999 Digital Security Controls Ltd. Toronto • Canada www.dscgrp.com Printed in Canada 29004757 R001...
