SETUP GUIDE /
CAPSTAN

Advertisement

loading
Need help?

Need help?

Do you have a question about the Capstan Genie II Linear and is the answer not in the manual?

Questions and answers

Related Manuals for Syrp Capstan Genie II Linear

Summary of Contents for Syrp Capstan Genie II Linear

  • Page 1 SETUP GUIDE / CAPSTAN...
  • Page 2 INSTALL THE CAPSTAN / Align the markings and insert the Capstan. Turn the Capstan counter clockwise until you hear a CLICK! Correct Rope Direction Incorrect Rope Direction The rope shouldn’t exit the channels and cross back over itself.
  • Page 3 REMOVE THE CAPSTAN / Push the Capstan Release button and hold in. Turn the Capstan clockwise and pull it out to remove it. UNLOCK...
  • Page 4 THREAD THE CAPSTAN / The Capstan is pre-wound, avoid removing unless absolutely necessary. Holding the Capstan with the bayonet end down, thread the rope in through the bottom channel from the right to the left. Wind 4x around Thread the rope around the Capstan until you can count 4 rope winds through the capstan window.

  • Page 5: Stay In Touch

    STAY IN TOUCH / Please stay in touch with us, join our community and show us your work. www.syrp.co youtube.com/syrptube vimeo.com/syrp instagram.com/syrp_ facebook.com/syrp.co.nz twitter.com/syrp_ syrp@syrp.co.nz...
