HIGH-FREQUENCY POWER TOOLS:
INEXPENSIVE POWER APPLICATION.
In spite of increasing automation in industrial production, the use of hand-held tools has
advantages in many work operations. These tools must fulfil several requirements: robustness,
powerful and a long service life, but they must also be easy to manage with high operating
comfort.
Better performance through
Unique
higher frequency
economy
Because their carbon brushes are
A further argument in favour of
subject to wear, universal motors of
high-frequency tools: their econo-
conventional power tools are unable
my. Their efficiency and thus their
to satisfy these requirements. On the
power consumption means that
other hand, the brushless asynchro-
they have unrivalled economy.
nous motor is ideally suited.
Their long service life and low
The current frequency it is supplied
maintenance requirements and
with determines its rotational speed,
power consumption offer an eco-
which, in turn, determines the out-
nomic solution for every type of
put that can be achieved. A higher
application.
frequency therefore means a higher
speed and a higher output.
Distinct environmental
consciousness
High power at a constant
speed
Environmental thinking plays a cen-
tral role in all Bosch products:
In continuous operation at 300 Hz,
from the initial development of the
Bosch high-frequency tools have a
idea and energy saving products, to
power output of up to 400 Watts
environmentally friendly packaging
per kg machine weight. In the short
and disposal.
term, peak performances of up to
If a Bosch high-frequency tool is
2.5 times this value are possible.
irreparably damaged, Bosch will
The speed remains almost constant
take back the old tool. They are col-
- irrespective of whether the tool is
lected centrally in the service centre
being operated at idle or full load.
and passed on for careful recycling.
2
Special power saving
measures
Bosch is also innovative in the
area of power saving and places an
emphasis on future-oriented tech-
nology: The heat recovery system
in the Murrhard plant, for example,
produces savings of over half a mil-
lion litres of heating oil a year.
Information
from the Internet
Bosch now offers users and others
interested in industrial tools all cur-
rent product information on the
Internet. Here you will find a free
online catalogue illustrating in text
and pictures all the common cord-
less, air and high-frequency tools for
industrial use. More information on
Page 4.
Conformity
All of the air tools listed in this
catalogue meet the following
standards or norm documents
EN 792, EN 50144, in accordance
with the regulations of Directives
89/392/EEC.
Certified in
accordance
with ISO 9001
Certificate no. FM 30078
All weight data in this catalogue corres-
ponds to the EPTA Procedure 01/2003.
CONTENTS.
5-12
Selection Guide for Drills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Drills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
13-44
Selection Guide for Sanders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Straight Grinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Angle Grinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Disc Sanders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
45-58
SCREWDRIVERS AND TAPPERS
Selection Guide for Screwdrivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Shut-off Screwdriver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Impact Wrenches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Tappers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
59- 62
Balancers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Plug-in Connections and Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
HIGH-FREQUENCY TECHNOLOGY
High-frequency technology correctly applied . . . . . . . . . . . . . . . . . . . .64
63-75
3
