Recommended cables:

For convenience, and high video quality we recommend the following Adder PS/2
and DVI cables.
The video cables are constructed to ensure that high video quality is maintained.
These cables are available in various different lengths to suit your requirements.
Please quote the following part codes when ordering from your supplier.
Part Code
VSC3
VSC8
VSA1
VSCD1
VSCD2
A3. Options port pin assignments
The 15 way D connector located on the back of the AdderView DVI (labelled
OPTIONS / FLASH) provides connections for the remote control module and allows
an external RS232 device to control the AdderView DVI. See section 3.6 for more
details.
Pin 9 = GND
Pin 10 = TXD
Pin 11 = RXD
Other pins to be left unconnected
AdderView DVI
Description
PS/2 PC to AdderView, 2 metres long
PS/2 PC to AdderView, 5 metres long
Serial to PS/2 mouse adapter
DVI-D single-link cable, 2 meters long
DVI-D single-link cable, 5 meters long
Installation and Use Page 38
