1.4 Product information

Figure 1 - AdderView DVI front view
User monitor
connection
Power connection
for optional power
adapter
User mouse
connection for
PS/2 style
mouse
Figure 2 - AdderView DVI rear view (4 port model)
Key for changing channels
Figure 3 - Remote control pad / display (optional accessory - part RC1)
AdderView DVI
Key for changing
channels. Also used
to access configure
mode
Computer mouse and keyboard connections
Keyboard coloured PURPLE
Mouse coloured GREEN
(1 to4)
Installation and Use
Display indicates
selected channel and
AdderView status
Computer video connections
coloured WHITE (1 to 4)
Display is duplicate of front
panel display and shows status
and mouse / keyboard data
activity
Options port – used
to connect remote
controller. Also used
to connect computer
for flash upgrades
