Creamsource SKY User Manual page 8

Scenario 11: 8 Bits - White and RGBW (V0 Compatibility Mode)
Slot No Slot Name
1 Master Level
2 CCT
3 Green/Magenta
4 White-Colour Crossfade
5 Red & Amber Combined
6 Green
7 Blue
8 White
Scenario 12: 8 Bits - White and Hue/Saturation (V0 Compatibility Mode)
Slot No Slot Name
1 Master Level
2 CCT
3 Green/Magenta
4 White-Colour Crossfade
5 Hue
6 Saturation
Scenario 13: 8 Bits – RGBW (V0 Compatibility Mode)
Slot No Slot Name
1 Master Level
2 Red & Amber Combined
3 Green
4 Blue
5 White
Scenario 14: 8 Bits - Hue/Saturation (V0 Compatibility Mode)
Slot No Slot Name
1 Master Level
2 Hue
3 Saturation
DMX Value
000 ... 255
000 ... 255
000 ... 010
011 ... 133
134
135 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
DMX Value
000 ... 255
000 ... 255
000 ... 010
011 ... 133
134
135 ... 255
000 ... 255
000 ... 255
000 ... 255
DMX Value
000 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
DMX Value
000 ... 255
000 ... 255
000 ... 255
