Creamsource SKY User Manual page 7

8 BIT MODES
Scenario 1: 8 Bits - White and RGBWA
Slot No Slot Name
1 Master Level
2 CCT
3 Green/Magenta
4 White-Colour Crossfade
5 Red
6 Green
7 Blue
8 White
9 Amber
Scenario 2: 8 Bits - White
Slot No Slot Name
1 Master Level
2 CCT
3 Green/Magenta
Scenario 3: 8 Bits - White and Hue/Saturation
Slot No Slot Name
1 Master Level
2 CCT
3 Green/Magenta
4 White-Colour Crossfade
5 Hue
6 Saturation
Scenario 4: 8 Bits - RGBWA
Slot No Slot Name
1 Master Level
2 Red
3 Green
4 Blue
5 White
6 Amber
Scenario 5: 8 Bits - Hue/Saturation
Slot No Slot Name
1 Master Level
2 Hue
3 Saturation
DMX Value
000 ... 255
000 ... 255
000 ... 010
011 ... 133
134
135 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
DMX Value
000 ... 255
000 ... 255
000 ... 010
011 ... 133
134
135 ... 255
DMX Value
000 ... 255
000 ... 255
000 ... 010
011 ... 133
134
135 ... 255
000 ... 255
000 ... 255
000 ... 255
DMX Value
000 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
000 ... 255
DMX Value
000 ... 255
000 ... 255
000 ... 255
Outsight Pty Ltd
Unit 6, 888 Bourke St, Zetland, Sydney NSW 2018, AUSTRALIA
+61-2-9669 8668
Output Value
0 ... 100%
2200 ... 15000K
Neutral
-100 to -1 Green
Neutral
+1 to +100 Green
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
Output Value
0 ... 100%
2200 ... 15000K
Neutral
-100 to -1 Green
Neutral
+1 to +100 Green
Output Value
0 ... 100%
2200 ... 15000K
Neutral
-100 to -1 Green
Neutral
+1 to +100 Green
0 ... 100%
0 ... 360 Degrees
0 ... 100%
Output Value
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
Output Value
0 ... 100%
0 ... 360 Degrees
0 ... 100%
