Creamsource SKY User Manual page 5

SPECIFICATIONS FOR FIXTURE
Model Number
Input
Maximum Ambient Temperature
Cooling
Weight
Protection Class
SPECIFICATIONS FOR POWER SUPPLY
Model Number
Input
Output
Maximum Ambient Temperature
Cooling
Weight
Protection Class
CSS-1200-C
2 circuits: 50.0V DC, Max 12.0A each, combined total draw 24A MAX
40°C
Passive (Silent)
23kg / 50lbs (head)
IP65 when all connector caps are fitted, or when Weipu connectors are mated (but not XLR DMX connectors)
CSS-PSU-1200
90-277V AC, 50-60Hz, 14A @ 115V, 6.6A @ 230V
2 circuits: 50.0V DC, 12.8A MAX each circuit, combined capacity 25.6A MAX
40°C
Passive (Silent)
13kg / 28lbs (power supply)
IP65 when all connectors are mated
Outsight Pty Ltd
Unit 6, 888 Bourke St, Zetland, Sydney NSW 2018, AUSTRALIA
+61-2-9669 8668
