Netio 4 / 4All Specifications - Netio PowerPDU 4C Manual

3.4

NETIO 4 / 4All specifications

Power
Switched outputs
Electrical load
Fuse
Internal consumption
Output relay
NETIO 4 interfaces
NETIO 4All interfaces
Environment
230 V; 50 Hz; max 15 A
NETIO 4/4All: 15 [8] A total per device / 8 A per output
Resistance load only
Built-in 15 A protection fuse
Max 4.1 W
Micro-disconnection (µ) (resistive load)
1E5 switching cycles, max. 1.5 kV pulse voltage
Switch heat and fire resistance class 1
1x Ethernet RJ-45 10/100 Mbit/s
1x Wi-Fi 802.11b/g/n 2.4 GHz (external 2 dBi antenna)
1x Ethernet RJ-45 10/100 Mbit/s
1x Wi-Fi 802.11b/g/n 2.4 GHz (3 dBi antenna, RSMA connector)
1x Bluetooth 4.0 Low Energy 2.4 GHz (BLE) (3 dBi, RSMA connector)
IP30, protection rating = class 1
Operating temperature 0 – 50 °C
Device rated for pollution degree 2.
Designed for continuous operation in altitudes up to 2000 m.
Does not require additional cooling
9
