  • Page 1 P a g e...

  • Page 2: Table Of Contents

    P a g e Contents Preface ..............................3 Safety Precautions ..........................4 Specifications ............................7 Specification Data ........................... 7 Unit Dimensions ..........................8 Unit Function Description........................9 Installation ............................10 5.1 Installation Space ..........................10 5.2 Installation Schematic Diagram ......................10 5.3 Installation Notes ..........................11 5.4 Water Loop Connection ........................11 5.5 Electrical Wiring ..........................11 5.6 Transit ..............................12...

  • Page 3: Preface

    P a g e 1. Preface This manual includes all the necessary information in regard to installation, debugging, discharging and maintenance of your unit. Ensure the contents of this manual are read carefully before the unit is opened or maintained. Read these operation and installation instructions carefully.

  • Page 4: Safety Precautions

    P a g e 2. Safety Precautions To prevent the users and others from being harmed while using this unit, to avoid damage to the unit and for to prevent improper use ensure that the following information is understood. The piping connection and wiring should be installed according to local legislation and to a professional standard.
  • Page 5 P a g e...
  • Page 6 P a g e...

  • Page 7: Specifications

    P a g e 3. Specifications 3.1 Specification Data EVO MAX EVO MAX 100 Hot Water Condition A20°C/15°C, W15°C to Heating Capacity kW 65°C Power Input kW C.O.P. WW 3.33 Hot Water L/h 1720 *Hot Water Condition A35°C/-°C, W15°C to Heating Capacity kW 75°C A35°C/-°C, W15°C to 70°C...

  • Page 8: Unit Dimensions

    P a g e 3.2 Unit Dimensions Evo Max 100...

  • Page 9: Unit Function Description

    P a g e 4 Unit Function Description HEATING CAPACITY The unit absorbs energy from outside and releases heat according to the heat exchanger, if the outside environment temperature is low, the heating capacity will be reduced. 3 MINUTE PROTECTION After the unit stops, if you restart the unit or turn on the manual switch then the unit will not run again for 3 minutes.

  • Page 10: Installation

    | 10 P a g e 5 Installation 5.1 Installation Space 5.2 Installation Schematic Diagram...

  • Page 11: Installation Notes

    | 11 P a g e 5.3 Installation Notes The unit can be installed in any outdoor area which can carry heavy machinery, such as a terrace, rooftop, the ground etc. The location must have adequate ventilation and be free from strong winds. The installation location must be free from heat radiation and fire hazards.

  • Page 12: Transit

    If the unit needs to be hung up during installation (for the Evo Max 100 unit, four sling wires longer than 8m are to be used. Use the special lifting hole (hook) on the unit base), an 8 metre cable will be needed to do so.

  • Page 13: Prior To Trial Operation

    | 13 P a g e 5.7 Prior to Trial Operation Check the piping system. Check whether the expansion water tank is filled with sufficient water and whether the water supply for supplement is normal. Check whether the entire piping system is full of water and whether the air is completely exhausted.

  • Page 14: Controlling And Operation

    | 14 P a g e 6. Controlling and Operation 6.1 Controller Display...

  • Page 15: How To Use The Controller

    | 15 P a g e 6.2 How to Use the Controller 6.2.1 Using the ‘Finger Point’ Button...

  • Page 16: Starting Up And Shutting Down

    | 16 P a g e 6.2.2 Starting Up and Shutting Down...

  • Page 17: System State Operation

    | 17 P a g e 6.2.3 System State Operation 6.2.4 Parameter Operations...

  • Page 18: Clock Operation

    | 18 P a g e 6.2.5 Clock Operation...

  • Page 19: Timer Operation

    | 19 P a g e 6.2.6 Timer Operation...
  • Page 20 | 20 P a g e...
  • Page 21 | 21 P a g e...
  • Page 22 | 22 P a g e...
  • Page 23 | 23 P a g e...

  • Page 24: Keyboard Lock

    | 24 P a g e 6.2.7 Keyboard Lock 6.2.8 Malfunction Display...

  • Page 25: Maintenance And Inspection

    | 25 P a g e 7. Maintenance and Inspection 7.1 Malfunction Table Malfunction Display Reason Resolution Power On Normal Working Inlet temp. sensor The temp. sensor is short Check or change the temp failure circuit or broken sensor Outlet temp. sensor The temp.

  • Page 26: Appendix

    | 26 P a g e 8. Appendix 8.1 Connection of PCB Illustration...
  • Page 27 | 27 P a g e...

  • Page 28: Cautions And Warnings

    | 28 P a g e 8.2 Cautions and Warnings The unit can only be repaired by qualified personnel or an authorised dealer. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 29: Cable Specification

    | 29 P a g e 8.3 Cable Specification 8.3.1 Single Phase Unit Nameplate max. Phase Line Earth Line Creepage Protector Signal Line current No More than 10A 2 x 1.5mm 1.5mm 30mA less than 0.1 sec 10~16A 2 x 2.5mm 2.5mm 30mA less than 0.1 sec 16~25A...
