ELECTRIC RANGE
Use & Care Guide
For questions about features, operation/performance,
parts, accessories or service, call: 1-800-253-1301.
or visit our website at...
www.estateappliances.com
Table of Contents ................................................. 2
To the installer: Please leave this
instruction book with the unit.
To the consumer: Please read and
keep this book for future reference.
9761863
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whirlpool TES325MQ1
Summary of Contents for Whirlpool TES325MQ1
- Page 1 ELECTRIC RANGE Use & Care Guide For questions about features, operation/performance, parts, accessories or service, call: 1-800-253-1301. or visit our website at... www.estateappliances.com Table of Contents ... 2 To the installer: Please leave this instruction book with the unit. To the consumer: Please read and keep this book for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS RANGE SAFETY ...3 The Anti-Tip Bracket ...3 PARTS AND FEATURES...5 COOKTOP USE ...7 Cooktop Controls...7 Ceramic Glass ...7 Coil Elements and Burner Bowls ...8 Lift-up Cooktop ...8 Home Canning ...8 Cookware ...9 ELECTRONIC OVEN CONTROL ...9 Oven Indicator Lights ...9 Display...9 Start/Enter ...10 Off/Cancel ...10... -
Page 3: Range Safety
Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock, injury to persons, or damage when using the range, follow basic precautions, including the following: WARNING: TO REDUCE THE RISK OF TIPPING OF THE RANGE, THE RANGE MUST BE SECURED BY PROPERLY INSTALLED ANTI-TIP DEVICES. -
Page 5: Parts And Features
This manual covers several different models. The range you have purchased may have some or all of the parts and features listed. The location and appearance of the features shown here may not match those of your model. Control Panel A. - Page 6 Range A. Surface cooking area or element B. Anti-tip bracket C. Door stop clip D. Model and serial number plate (behind left side of storage drawer) E. Storage drawer F. Control panel G. Hot surface indicator light (on ceramic glass models) H.
-
Page 7: Cooktop Use
Cooktop Controls WARNING Fire Hazard Turn off all controls when done cooking. Failure to do so can result in death or fire. The control knobs can be set anywhere between HI and LO. Push in and turn to setting. On some models, the surface cooking area locator shows which element is turned on. -
Page 8: Coil Elements And Burner Bowls
Use flat-bottomed cookware for best heat conduction and energy efficiency. Cookware with rounded, warped, ribbed or dented bottoms could cause uneven heating and poor cooking results. Determine flatness by placing the straight edge of a ruler across the bottom of the cookware. While you rotate the ruler, no space or light should be visible between it and the cookware. -
Page 9: Cookware
Cookware IMPORTANT: Do not leave empty cookware on a hot surface cooking area, element or surface burner. Ideal cookware should have a flat bottom, straight sides and a well-fitting lid, and the material should be of medium-to-heavy thickness. Rough finishes may scratch the cooktop. Aluminum and copper may be used as a core or base in cookware. -
Page 10: Start/Enter
Start/Enter The Start/Enter pad begins any oven function. If the Start/Enter pad is not pressed within 5 seconds after pressing a function pad, the “Start?” indicator light will flash as a reminder. If Start/Enter is not pressed within 1 minute after pressing a function pad, the oven display will return to the time of day mode and the programmed function will be canceled. -
Page 11: Oven Temperature Control
IMPORTANT: Do not use a thermometer to measure oven temperature because opening the oven door and element or burner cycling may give incorrect readings. The oven provides accurate temperatures; however, it may cook faster or slower than your previous oven, so the temperature calibration can be adjusted. -
Page 12: Oven Use
Odors and smoke are normal when the oven is used the first few times, or when it is heavily soiled. IMPORTANT: The health of some birds is extremely sensitive to the fumes given off. Exposure to the fumes may result in death to certain birds. -
Page 13: Meat Thermometer
Meat Thermometer On models without a temperature probe, always rely on a meat thermometer to determine doneness of meat and poultry. The internal temperature, not appearance, is what counts. A meat thermometer is not supplied with this appliance. Insert the thermometer into the center of the thickest portion of the meat or inner thigh or breast of poultry. -
Page 14: Broiling Chart
To Broil: 1. Press CUSTOM BROIL. The broil oven indicator light will light 2. Press START/ENTER. The On and Heat oven indicator lights will light up. The temperature setting can be changed any time before or after pressing START/ENTER. See “Custom Broiling” section. If broiling while the time is counting down, the set broiling temperature can be seen for 5 seconds by pressing CUSTOM BROIL. -
Page 15: Range Care
Self-Cleaning Cycle (on some models) WARNING Burn Hazard Do not touch the oven during the Self-Cleaning cycle. Keep children away from oven during Self-Cleaning cycle. Failure to follow these instructions can result in burns. IMPORTANT: The health of some birds is extremely sensitive to the fumes given off during the Self-Cleaning cycle. -
Page 16: General Cleaning
IMPORTANT: Before cleaning, make sure all controls are off and the oven and cooktop are cool. Always follow label instructions on cleaning products. Soap, water and a soft cloth or sponge are suggested first unless otherwise noted. EXTERIOR PORCELAIN ENAMEL SURFACES (on some models) Food spills containing acids, such as vinegar and tomato, should be cleaned as soon as the entire appliance is cool. -
Page 17: Oven Cavity
SURFACE UNDER COOKTOP (on some models) Do not remove the cooktop to avoid product damage. For more information, see “Lift-up Cooktop” section. Steel-wool pad OVEN DOOR EXTERIOR Glass cleaner and paper towels or nonabrasive plastic scrubbing pad: Apply glass cleaner to soft cloth or sponge, not directly on panel. -
Page 18: Storage Drawer
4. Pull door straight up, then toward you. Hinge hangers will slide out of front frame hinge slot. Do not remove door removal pins until the door is replaced on the range. To Replace: 1. Grasp the door on the sides with your fingers on the front of the door and your thumbs on the inside surface. -
Page 19: Assistance Or Service
Pages. replacement parts will fit For further assistance ® appliance. If you need further assistance, you can write to Whirlpool Corporation with any questions or concerns at: Estate Brand Home Appliances Customer eXperience Center 553 Benson Road Benton Harbor, MI 49022-2692 Please include a daytime phone number in your correspondence. -
Page 20: In The U.s.a
CLEANTOP Whirlpool Corporation warrants that the ceramic glass cooktop will not discolor, the cooktop pattern will not wear off, the rubber seal between the ceramic glass cooktop and porcelain edge will not crack, the ceramic glass cooktop will not crack due to thermal shock and the surface unit elements will not burn out.
