Carel EASY COOL Manual

+050004121 - rel. 1.1 - 28.07.2011
:
EASY COOL
(PZD*S*P***)
Dimensions (mm)
74
81
Panel mounting
Front (with 2 screws ø 2,5x12 mm)
1
max 2,5
Rear (with 2 quick-fi t side brackets)
PZD0SNP0E1
2
1
PZD4S0P001, PZD4S0P101
2
1
Electrical connections
PZD0SNP0E1
230 Vac
PZD4S0P001
-10T50
EN60730-1
250 Vac
UL 873
3 4 5
PZD4S0P101
-10T50
EN60730-1 12(2)A
250 Vac
UL 873 12A 5FLA 30LRA
3 4 5
electronic controllers for normal temperature static refrigeration units
READ CAREFULLY IN THE TEXT!
PZD0SNP0E1
71x29
31
38,29
PZD4S0P001
PZD4S0P101
58
65,29
2
Pozidriv type
Do not tighten
excessively
If necessary, remove the covers to simplify wiring
Fig.4
Fig. 3
SERIAL
CONV
12(2)A
12A 5FLA 30LRA
PROG.
NTC
KEY
PROBES
6 7 8 9 10 11
L N
L 230V~
SERIAL
CONV
PROG.
NTC
KEY
PROBES
6 7 8 9 10 11
L N
L 115V~
Description
NO POWER
& SIGNAL
CABLES PJEZ* represents a range of electronic microprocessor controllers with LED display developed for the manage-
TOGETHER
ment of refrigerating units, display cabinets and showcases; are designed for the management of static refrigera-
ting units (no fan on the evaporator) operating at temperatures above 0°C.
Technical specifi cations
• Electronic controllers for normal temperature static refrigeration units
• Power supply 115Vac or 230Vac
• Ambient probe NTC
• Compressor relay 16A
Display and functions
During normal operation, the controller displays the value of the temperature read by probe. In addition, the
10
display has LED that indicate the activation of the control functions (see Tab. 1), while the 3 buttons can be used
3
to activate/deactivate some of the functions (see Tab. 2).
Compressor LED signals
10
icon function
3
compressor status on
Fig.1
Table of functions activated by the buttons
3
button
pressing the button alone
up more than 3 s:
ON/OFF toggle ON/OFF
down more than 3 s:
defrost start/stop defrost
set mute - 1 s.: display/set the set point
Fig.2
- more than 3 s: access
parameter setting menu
(enter password '22')
Setting the setpoint (desired temperature)
Step Action
1
Keep SET button pressed
for 2 s
2 Press UP or DOWN
buttons
3 Press SET button
Accessing and setting the parameters
Step Action
1 Keep SET button
pressed for 3 s
2 Press SET button again
3 Press UP or DOWN button
4 Press SET button
5 Press UP or DOWN button
6 Press SET button
7 Press UP or DOWN button
8 Press SET button
9 Repeat steps 5, 6, 7 and 8 for
all desired parameters
10 Keep SET button
pressed for 5 s
Fig.5
normal operation
ON OFF
off ON request in
progress
normal operation
pressed together
Pressed together start/
stop
continuous cycle
-
Effect Meaning
After 1 sec currently setpoint value will It's regulation setpoint
fl ash on display currently active
Setpoint value will chang Set desired value
Controller will visualize temperature read setpoint is modifi ed and
by probes again saved
Effect
After 3 s display will visualize "PS"
Display will visualize "0" blinking
Visualized value on display will change
After 5 s the fi rst parameter, "/5", will be
visualized on display
Parameter list will be scrolled on display
(refer to Table of parameters)
Display will visualize value of the selec-
ted parameter
Parameter value visualized on display
will change
Display will visualize parameter name
again
Controller will visualize temperature
read by probes again
start up
blink
ON
Tab. 1
start up
-
for 1 s display fi rmware
vers. code
for 1 s RESET current
EY set
Tab. 2
Tab. 3
Meaning
Password is requested
Insert password "22"
It's the name of the fi rst
parameter
Select desired parameter
It's the currently parameter
value
Set desired value
Attention: parameters
updating is not yet active
Attention: now parameters
updating will be active
Tab. 4
