Technical Information - DEFA MultiCharger 40A 24V User Manual

Electrical data input
Mains voltage
Mains frequency
Mains current
Efficiency
Effective power
Power consumption (standby)
Protection class
EMC emission
Electrical data output
Nominal output voltage
Output voltage range
Output current
Battery return current
Mechanical data
Cooling
Dimensions (l x w x h)
Weight (without cable)
AC Power cable length
DC charging cable length
Environmental conditions
Operating temperature
Storage temperature
Climate class
Degree of protection
Standards
DEFA confirms that these chargers satisfy relevant safety requirements according to prevailing regulations and standards.

TECHNICAL INFORMATION

220-240 V AC
50/60 Hz
max. 5.9 A eff.
max. 95 %
max. 1224 W
N/A
I
Class A
24 V DC / 2x6 cells
4–30.6 V DC
40 A at 28.8 V DC
< 1 mA
Convection
262 x 157 x 85 mm
4.8 kg
1 m
2 m
-35°C - +40°C
-40°C - +85°C
B
IP67
EN 60335-1, EN 60335-2-29, EN 61000-6-2 (EN 61000-4-2,
EN 61000-4-3, EN 61000-4-4) (EN 61000-4-5, EN 61000-4-6,
EN 61000-4-11), EN 61000-6-4 (Class A)
5
