  • Page 1 SmartCharge User Manual...
  • Page 2: Product Warnings

    Product warnings Save these instructions - this manual contains important safety instructions. Do not operate the battery charger unless you have read and understood this manual and the charger is setup as per these installation instructions. 1. Risk of explosive gases: Working in the vicinity of a Lead-Acid battery is dangerous.
  • Page 3 does not exceed the manufacturer’s recommended maximum charging current. 7. Batteries can emit explosive gases during normal charging. Avoid sparks in the immediate area and always provide proper ventilation during charging. 8. Connect the charger’s positive clamp to the positive terminal on the battery.
  • Page 4: Setting Up The Charger

    Plug the mains plug into a 240VAC mains power socket and turn the charger ON. Operation DEFA SmartChargers provide battery charging for a range of vehicles and equipment such as cars, motorbikes, 4x4s, recreational vehicles, lawnmowers, jet skis and boats etc.
  • Page 5 Charging Profi le The charger begins charging with a constant current until the voltage reaches 14.4V (at 25°C). The charge voltage is then held constant at 14.4V and the charging current is reduced until it is below a predefi ned level. The charge voltage then drops to 13.8V, before the long-term charging stage starts.
  • Page 6 Additional charger functionality Temperature based voltage compensation The charger automatically adjusts the charging voltage to the correct level according to the ambient temperature. The default ambient temperature is 25°C. Voltage is reduced for higher ambient temperatures and increased for lower ambient temperatures by ±0.03V/°C. Max temperature compensate charging voltage is 15.3 V.
  • Page 7 Automatic restart after mains supply interruption If the mains supply is temporarily interrupted, the charger will continue charging when the power supply returns. Safety features • Incorrect polarity protection • Spark protection • Short circuit protection • Over-current protection • Over-temperature protection •...
  • Page 8: Technical Data

    Technical data Type (SBC1204) (SBC1206) Battery size (V/Ah) 12/2-110 12/10-150 Input (VAC/Hz) 230 /50-60 Power Consumption (W) Output Voltage (V) 14.4/14.7 Output current (A) 4 (max) 6 (max) Reverse current (mA) I drain <1 IP class (IP) Type (SBC1208) (SBC1210) Battery size (V/Ah) 12/20-200 12/30-250...
  • Page 9 Over the last three decades our company has established a reputation as the power conversion specialist. A 100% Australian-owned company, we have met the needs of customers in transport and other industries through exciting, innovative thinking. We believe in total customer satisfaction and practice this by off...
  • Page 10 Redarc Electronics Pty Ltd atf the Redarc Trust trading as Redarc Electronics (“Redarc”) off ers a warranty in respect of its Products where the Products are purchased from an authorised distributor or reseller of Redarc by a person (“Purchaser”), on the terms and conditions, and for the duration, outlined below in this document (“Warranty”).
  • Page 11 any repaired or replaced Products or components of Products to the Purchaser’s usual residential address notifi ed to Redarc, together with the reasonable costs of removal and return of any Products determined by Redarc to be defective. 5. If the Purchaser incurs expenses of the nature referred to in clause 4 in the context of making a claim pursuant to this Warranty that is accepted by Redarc, the Purchaser will be entitled to claim for...
  • Page 12 6.5 repairs to the Product that are not strictly in accordance with Redarc’s instructions; 6.6 installation, repairs or maintenance of the Product by, or under the supervision of, a person who is not a qualifi ed auto electrician or technician, or if non-genuine or non- approved parts have been fi...
  • Page 13 8. Without limiting any other clause in this Warranty, Redarc has the right to reject any Warranty claim made by a Purchaser pursuant to this Warranty where: 8.1 the Purchaser does not notify Redarc in writing of a Warranty claim within the Warranty Period;...
  • Page 14 a Product (diff erent in size, colour, shape, weight, brand and/or other specifi cations) in fulfi lling its obligations under this Warranty, in the event that Redarc has discontinued manufacturing or supplying the relevant Product or component at the time of the Warranty claim, or where such Product or component is superior to that originally purchased by the Purchaser.
  • Page 15 17. Spare parts or materials for the Products are guaranteed to be available for a period of at least 5 years after purchase of the Products. 18. The agents, offi cers and employees of any distributor or reseller of the Products and of Redarc are not authorised to vary or extend the terms of this Warranty.
  • Page 16 Free technical assistance! please contact REDARC Electronics 23 Brodie Road North, Lonsdale SA (08) 8322 4848 power@redarc.com.au www.redarc.com.au Copyright © 2018 REDARC Electronics Pty Ltd. All rights reserved. redarc.com.au 709597_E00 WARSBCV2-REV1...
