Vendor: S000053
ASSEMBLY INSTRUCTIONS
FARO 4' BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR FARO
4' BED FRAME
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
www.birlea.com
Page 1 of 5
Advertisement
Table of Contents
Related Manuals for Birlea Faro Bed
Summary of Contents for Birlea Faro Bed
- Page 1 Periodically check all screws & fixings to ensure they are secure. DO NOT push the bed frame as this will damage the legs. Always lift the bed with two people to reposition. Keep any sharp objects away from the frame. www.birlea.com Page 1 of 5...
- Page 2 Vendor: S000053 Parts List Hardware List (found in box 1) Part Description Part Description Headend 50 mm Black Round Stopper Footend M6 x 16 mm JCBC Screw Side Support M6 x 50 mm JCBC Screw Side Frame M6 Nut Mid Support M8 x 50 mm JCBC Screw Base Leg M8 Nut...
- Page 3 Vendor: S000053 Step 1: Insert hardware part A to the headend (1) and footend (2). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 2: Fix the side supports (3) to the headend (1) and footend (2) using hardware part A but do not fully tighten yet.
- Page 4 Vendor: S000053 Step 4: Place the mid support (5) on top of the side frames (4) and tightly secure using hardware parts E and DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 5: Fit the base legs (6) to the mid support (5) according to the holes at the side, then tightly secure using hardware parts D and G.
- Page 5 • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
