AUDIO INTERFACE UNIT
This manual offers not only the installation and usage of the IR-801AF US DQ but also the
general descriptions for the entire Wireless microphone system* such as system configuration
and connection.
For details about the system components, refer to the instruction manual attached to each
component.
*
The Wireless microphone system is comprised of the following components:
•
IR-802T CU AQ, IR-802T CU 1Q Infrared Wireless Tuner
•
IR-820SP Y 4Q Infrared Wireless Speaker
•
IR-310M Y PQ and IR-200M Y 4Q Infrared Wireless Microphones
•
IR-310BC and IR-200BC Battery Charger
•
IR-200BT-2 Ni-MH Battery
Thank you for purchasing TOA's Audio Interface Unit.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TOA Canada Corporation
INSTRUCTION MANUAL
IR-801AF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IR-801AF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toa IR-801AF

Summary of Contents for Toa IR-801AF

  • Page 1 INSTRUCTION MANUAL AUDIO INTERFACE UNIT IR-801AF This manual offers not only the installation and usage of the IR-801AF US DQ but also the general descriptions for the entire Wireless microphone system* such as system configuration and connection. For details about the system components, refer to the instruction manual attached to each component.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. IMPORTANT SAFETY INSTRUCTIONS ................3 2. SAFETY PRECAUTIONS ....................3 3. GENERAL DESCRIPTION ....................4 4. FEATURES ........................5 5. HANDLING PRECAUTIONS ....................5 6. NOMENCLATURE AND FUNCTIONS ................5 [Front] ............................5 [Rear] ............................6 7.

  • Page 3: Important Safety Instructions

    1. IMPORTANT SAFETY INSTRUCTIONS • Read these instructions. • Only use attachments/accessories specified by the manufacturer. • Keep these instructions. • Use only with the cart, stand, tripod, bracket, • Heed all warnings. or table specified by the manufacturer, or sold •...

  • Page 4: General Description

    820SP. And in separate mode, each audio signals from two IR-802T passes through into each IR- 820SP. The IR-801AF US DQ is equipped with a single channel wireless tuner having a fixed frequency. It makes a priority the IR-310M Y PQ and makes mute other infrared microphone when receiving a priority control signal transmitted through the priority switch operation of the IR-310M Y PQ.

  • Page 5: Features

    4. FEATURES • Only CAT. 5 straight cable fitted with RJ-45 connecters for connections from the IR-801AF to each of the IR-802T and the IR-820SP. • Makes a priority the IR-310M Y PQ and makes mute other infrared microphone while the priority switch operation of the IR-310M Y PQ.

  • Page 6: [Rear]

    [Rear] AUDIO OUT CONTROL OUT TO IR-820SP TO IR-802T DC24V H C E MADE IN TAIWAN 6. IR-802T CU AQ connection terminal* 9. DC inlet terminal Connect this terminal to the IR-802T CU AQ Connect the optional AC adapter. Infrared Wireless Tuner using a Category 5 cable (straight type).

  • Page 7: System Configuration

    Infrared Wireless microphone Student 2: channel “1” Student 3: channel “2” IR-200M Y 4Q Infrared Wireless Microphone Student 1: channel “B” IR-801AF US DQ Audio Interface Unit (Combine mode) IR-310M Y PQ Infrared Wireless Microphone IR-802T CU 1Q Teacher: channel “A”...

  • Page 8: Two Channels System For Large Class Room

    Teacher: channel “A” 8. CONNECTIONS 8.1. Connections for four channels system Cable “a” Cable “b” IR-820SP Y 4Q IR-820SP Y 4Q Notes: • The IR-801AF's power is supplied from the IR-802T Category 5 cable • The connecting (straight type) positions of IR-802T...

  • Page 9: Connections For Two Channels System

    8.2. Connections for two channels system Cable “a” Cable “b” IR-820SP Y 4Q IR-820SP Y 4Q Category 5 cable (straight type) IR-801AF US DQ Category 5 cable (straight type) To AC mains IR-802T CU AQ AC adapter To AC mains...

  • Page 10: Priority Control For System

    Toggle on the Priority function switch of IR-310M Y PQ while speaking, audio from the channel "B" in IR-802T CU AQ makes mute, and audio from IR-802T CU 1Q also makes mute in IR-801AF US The channel "B", "1" and "2" as the student microphone are muted.

  • Page 11: Four Channels System For Dual Zone Class Rooms

    IR-200M Y 4Q Infrared Wireless microphone Student 2: channel “2” IR-200M Y 4Q Infrared Wireless Microphone Student 1: channel “B” IR-801AF US DQ Audio Interface Unit (Separate mode) IR-310M Y PQ Infrared Wireless Microphone IR-802T CU 1Q Teacher 1: channel “A”...

  • Page 12: Rack Mounting

    210 (w) x 44 (h) x 181 (d) mm (8.27" x 1.73" x 7.13") Weight 560 g (1.23 lb) Note: The design and specifications are subject to change without notice for improvement. • Optional product MB-WT3 Rack Mount Kit www.toacanada.com TOA Canada Corporation 133-07-00126-00...
