GENERAL This is an electric machine user manual, in which operation, maintenance and safety information are specified . Please read and file it carefully . After unpacking, please check to ensure your machine has not been damaged during shipping . Please notify your service representative or qualified technician regarding all questions or concerns before installing .
Every machine has an identification label placed on the front of the machine . The label includes information of model number, voltage, serial number, wattage, and its certificate . Please do not remove this label in order for technician to check electrical information in the future . 236ECEM1 236ECEM2 236ECEM3 Groups Boiler Capacity 6 Qt .
Page 5
SETUP ( CONTINUED ) STARTING THE AUTOMATIC MACHINE 1 . Check and confirm that water source is in normal working order . 2 . Turn the power switch to position 1 to initiate automatic system check . If boiler water level is not in the green zone, wait until the automatic water replenishment process is complete before proceeding to the next step .
OPERATION BREWING 1 . Fill the porta filter with coffee grounds and tamp . 2 . Secure the port filter to the espresso machine with a quarter turn . 3 . Use any of the presets to brew or use the continuous flow button . 4 .
CLEANING & MAINTENANCE MACHINE BODY 1 . Wipe machine exterior with soft, slightly dampened cloth daily before starting operations . 2 . If necessary, a mild, non-corrosive cleaning agent may be applied to the cloth . DO NOT spray cleaning agents directly on the machine body to avoid corrosion and possible damage to circuits .
Page 8
CLEANING & MAINTENANCE ( CONTINUED ) STEAM TUBE 1 . After making steamed milk, use a slightly moistened soft cloth to wipe steam tube . 2 . After wiping, release a steam burst through the tube to remove any residual milk remaining in the nozzle .
PARTS DIAGRAM Description Description Hot Water Knob Foot Espresso Brewing Unit Control Panel Sight Glass (Boiler Level Check Window) Steam Knob 10 Espresso Filter Holder Brewing Group 11 Cup Rack Steam Wand 12 Pump Pressure Gauge 13 Steam Boiler Pressure Gauge Main Switch 14 Hot Water Wand Drain Tray...
WIRING DIAGRAM 236ECEM1 110±10% V 1Φ 50/60Hz N1(110VAC) ssr switch pressure switch wiring diagram heater power switch Motor connector &pump keyboard group1 connector Water valve Water probe ssr signal Flower meter1(group1) Dosing setting Group1 valve...
WIRING DIAGRAM 236ECEM2 220±10% V 1Φ 50/60Hz N2(220VAC) ssr switch pressure switch wiring diagram heater power switch Motor connector &pump keyboard group2 group1 connector Water valve Water probe ssr signal Flower meter2(group2) Flower meter1(group1) Dosing setting Group2 valve Group1 valve...
LIMITED WARRANTY Estella warrants its equipment to be free from defects in material and workmanship for a period of 1 year . This is the sole and exclusive warranty made by Estella covering your Estella brand equipment . A claim under this warranty must be made within 1 year from the date of purchase of the equipment .
