RoadScan Canada DC1 User Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
RoadScan Canada
DC1
User Instruc on Manuals

Advertisement

loading
Need help?

Need help?

Do you have a question about the DC1 and is the answer not in the manual?

Questions and answers

Related Manuals for RoadScan Canada DC1

Summary of Contents for RoadScan Canada DC1

  • Page 1 RoadScan Canada User Instruc on Manuals...
  • Page 2 RSC DC1 User Manual 1. USB 2. GPS 3. Power ON/OFF 4. Lens 5. Charging Indicator 6. Recording Indicator 7. GPS Indicator 8. Reset 10. OK / Recording/ One Bu on Emergency Recording 11. Back / Menu 12. Up / Playback 13.
  • Page 3 RSC DC1 User Manual POWER Using the a achment plate, find a suitable loca on for the camera that is free of obstruc on. It is important to clean the windshield well in the area that the camera will be located prior to a aching the fixed plate (See setup and installa on).
  • Page 4 RSC DC1 User Manual Red light = The camera is plugged in to 12 volt, USB, or hard wired. Figure 2 Blue light = video recording is in progress. Figure 3 Green Light = GPS is ac ve and recording...
  • Page 5 RSC DC1 User Manual Screen Icons by number: Figure 5 1. Red Light Flashing/ me = Recording in progress 2. WIFI symbol = Indicates if WIFI is connected or not 3. Plug – Indicates that the camera is plugged-in/charging. 4. Lower right corner of screen – white wri ng = license plate number, speed, me and date (this allows the user to view the video in windows media without the GPS program and s ll provide the necessary informa on).
  • Page 6 RSC DC1 User Manual Figure 6 5. Emergency – Indicates when the camera is in emergency mode. When the camera is in this mode the video will be stored in a separate folder named ‘emergency’. The data in this folder cannot be overwri en on the camera and must be deleted manually.
  • Page 7 BUTTONS & MENU ACCESS Figure 7 Figure 8 There are five essen al bu ons on the DC1. 1. POWER bu on located on the le side of the camera 2. OK bu on, top le corner from screen 3. MENU bu on (below OK bu on) 4.
  • Page 8 RSC DC1 User Manual If the camera is recording, you can press the SCROLL DOWN bu on to stop recording and then press the MENU bu on to enter the menu. Also, if the camera is recording you can just press the MENU bu on and the camera will automa cally stop recording and enter the menu.
  • Page 9 RSC DC1 User Manual Figure 10 Photo Resolu on: Change the resolu on of photos taken in camera mode. Op ons are: 13M (4800x2700), 9M (4000x2250), and 4M (2688x1512) Image Quality: Change the quality of the photos captured by camera. Op ons are S.Fine (Super Fine) / Fine/ Normal EV (Exposure Value): Op ons are: -2.0 EV, -1.7 EV, -1.3 EV, -1.0 EV, -0.7 EV, -0.3 EV, 0.0 EV, +0.3...
  • Page 10 RSC DC1 User Manual Figure 11 Voice Record: Op ons: On / Off. If On the camera will record audio while recording video. If off, the camera will not record audio. If the audio is manually muted or unmuted (via momentarily holding the SCROLL UP bu on), this will show in the se ng.
  • Page 11 RSC DC1 User Manual Figure 12 Record Interval: Video recordings are split into segments (separate files) when the recording interval passes the set me. Op ons are: 3 and 5 minutes, this makes for easier viewing and shorter download me.
  • Page 12 RSC DC1 User Manual Figure 13 File Dele on: entering this se ng will give you the op on to delete files. There are two folders: video and emergency. (See File Playback and Dele on) ● Video will have all your video and photo files.
  • Page 13 RSC DC1 User Manual RECORD MODE / EMERGENCY MODE When the camera is powered up, it will automa cally begin recording. To stop the recording press the SCROLL DOWN bu on. To start a recording push the OK bu on.
  • Page 14 RSC DC1 User Manual File Playback and File Dele on File playback allows you to view all recordings the camera has captured. There are two ways to view files. 1. Exit record mode and press the SCROLL UP bu on which will navigate you to the video folder, which has all your recordings, including photos.
  • Page 15 RSC DC1 User Manual Figure 17 To navigate through this menu, use the SCROLL UP and SCROLL DOWN bu ons. Press OK to view a file. If the file you press OK bu on on is a video file, the file will automa cally start playing.
  • Page 16 RSC DC1 User Manual Choose one of the files you would like to delete from. Figure 19 Just like File PlayBack, navigate through your file by pressing SCROLL UP and SCROLL DOWN and press OK to select the file you would like to delete. When you press the OK bu on, the menu screen below will appear.
  • Page 17 RSC DC1 User Manual Opening Files On the Computer 1. Plug the camera into the computer via the USB cable 2. A red light should be lit on the camera 3. The camera screen should turn blue and have the words ‘usb connec ng…’ displayed 4.
  • Page 18 RSC DC1 User Manual Select NORMAL to view all of your camera’s recorded files Figure 22 Figure 23 Page 17...
  • Page 19 RSC DC1 User Manual To View Event Video: Open the Event folder. The videos located in this folder are the ones captured when the camera exceeded the G-Force parameters set. These videos can only be deleted on the computer. Select the video to view it, open with windows media player.
  • Page 20 RSC DC1 User Manual To Delete Files : To delete files, go back to the folder of “D”, ‘E’, ‘F’, or ‘G’ drive and highlight and delete the selected files by pressing delete (like any thumb drive). Ensure all files to be kept are saved in another loca on on your computer prior to dele ng files.
  • Page 21 RSC DC1 User Manual Setup and Installa on Installing memory card: 1. Make sure of the inser on direc on of the TF card. Improperly inser ng could damage the unit and or the TF card. 2. Be sure to use a high-speed TF card with SDHC specifica on which has the logo of C10 or above 3.
  • Page 22 RSC DC1 User Manual The bracket can be freely adjusted to meet the needs of your vehicle. Once you have angled your bracket you can ghten the bracket so the camera will stay in the same posi on (See Figure 29 - 30):...
  • Page 23 RSC DC1 User Manual To remove the bracket: pinch the base of the bracket with your thumb on the ejector (circled in red in image below) and pull the bracket off. Figure 31 A aching camera to windshield: To ensure op mized viewing, ensure that the camera is set up on the windshield with no view obstruc ons.
  • Page 24 RSC DC1 User Manual *If you wish to use the suc on cup, the steps to a ach the suc on cup to camera is the same as the bracket. When a aching the suc on cup to the windshield, find a clean spot and push the suc on switch on the suc on cup towards the cup to a ach.

  • Page 25: Warranty

    Monitoring one’s private ac vi es without consent is illegal and this product is not designed or manufactured for these purposes. • DO NOT use this product to carry out any illegal ac vi es such as sneak preview, etc. RoadScan Canada Inc shall not be responsible for any consequences of illegal conducts made by users.
