Intertek DONYER POWER CH-1500 Owner's Manual page 7

ATTACHING HEATER TO MOUNTING BRACKET
i WARNING
1. The heater is equipped with Rotating Arms at each end of the unit.
To conserve space in shipment, these arms are in line with the
heater body and must be repositioned before installation. With
your heater laying face down, rotate each arm slowly upward
until they are perpendicular to the body. For safety reasons,
once rotated, the arms cannot be returened to their original
position.
2. Holding the heater by the Rotating Arms (one in each hand), slide
the Rotating Arms onto the Mounting Bracket until it locks into
place.
3. Place the 2 x M4*25 Screws into each Rotating Arm with the nut
after the heater is attached to the Mounting Bracket. See Fig. 2
4. Plug the unit directly into a 120V AC grounded outlet. Keep the
cord away from the front of the heater. Do not use an extension
cord, because the extension cord may overheat and cause a risk
i
CAUTION
Always remove the Screw from each Rotating Arm before attaching
heater to Mounting Bracket. Do not forget to put the Screws back in
each Rotating Arm after attaching the heater. Otherwise, the heater
could slide out of Mounting Bracket and cause injury or damage.
Do not adjust the heater while it is operating. The metal parts of the
housing and the lampshade get very hot and can cause injury. Always
turn your heater off and allow time for it to cool before adjusting.
Fig. 2
7
