Intertek DONYER POWER CH-1500 Owner's Manual

Wall mounted garage heater
Hide thumbs

Advertisement

Table of Contents

R
DONYER POWER
OWNER'S MANUAL
WALL MOUNTED
GARAGE HEATER
MODEL: CH-1500
Read and understand this entire owner's manual, including all safety information,
i WARNING
before
electric shock, or serious personal injury.
CAUTION
Keep this owner's manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DONYER POWER CH-1500 and is the answer not in the manual?

Questions and answers

Related Manuals for Intertek DONYER POWER CH-1500

Summary of Contents for Intertek DONYER POWER CH-1500

  • Page 1 DONYER POWER OWNER’S MANUAL WALL MOUNTED GARAGE HEATER MODEL: CH-1500 Read and understand this entire owner’s manual, including all safety information, i WARNING before electric shock, or serious personal injury. CAUTION Keep this owner’s manual for future reference.

  • Page 2: Important Instructions

    This owner’s manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Thoroughly read the instructions and familiarize yourself with all the operational aspects of your new product. IMPORTANT INSTRUCTIONS When using this electric unit, basic safety precautions should always be followed to reduce the risk of re, electric shock, and injury to persons, including the following: 1.
  • Page 3 10. DO NOT insert or allow foreign objects to enter any ven- tilation or exhaust opening as this may cause an electric shock or re, or damage the heater. 11. To prevent a possible re, DO NOT block the air intakes or exhaust in any manner.

  • Page 4: Specifications

    SPECIFICATIONS VOLTAGE RATING 120 V (60Hz) 12.5 Amps POWER CONSUMPTION 500W 23.6 in W x 3.1 in D x 15.5 in H UNIT SIZE 7.3 lbs UNIT WEIGHT SAFETY FEATURES Overheat Safety Feature This heater is equipped with an overheat safety feature. When the heater’s internal components reach a certain temperature that could cause overheating and possible re, the heater will automatically shut off.

  • Page 5: Product Diagram

    IN THE BOX • Wall Mounted Garage Heater 3 x ST*35 Screws • • • 3 x Wall Anchors 1 x Mounting Bracket 2 x M4* 25 Screws 2 x Nuts • • • 1 x Metal Washer • Owner’s Manual PRODUCT DIAGRAM LED Light Mounting Bracket...
  • Page 6 KEY SLOT MOUNTING INSTALLATION Heater should be at least 3 feet away from combustible material. The i WARNING heater is wall mounted only, not suitable for ceiling mounting. 1. Locate a desired position on your wall in the area to be warmed. MUST be near an outlet.
  • Page 7 ATTACHING HEATER TO MOUNTING BRACKET Always remove the Screw from each Rotating Arm before attaching heater to Mounting Bracket. Do not forget to put the Screws back in i WARNING each Rotating Arm after attaching the heater. Otherwise, the heater could slide out of Mounting Bracket and cause injury or damage.
  • Page 8 REMOVING HEATER FROM MOUNTING BRACKET Unplug the unit and let it cool completely. Remove Screws from each Rotating Arm. Push-in the two arm release button on the side of each arm. Grasp both arms and simultaneously pull the unit down while holding the buttons in.

  • Page 9: Maintenance

    MAINTENANCE 1. Set the power to OFF Position. 2. Unplug the unit and let it cool completely. 3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth. A mild detergent can be used if necessary.

  • Page 10: Troubleshooting

    TROUBLESHOOTING If the heater will not operate, please check the following: 1. Check if the power cord is plugged into an electrical outlet. If not, plug in unit to appropriate outlet. 2. Check if electricity to the outlet is working 3.
