  • Page 1 INSTRUCTION MANUAL Pick and Place unit Ref. PK-5A...

  • Page 2: Packing List

    The following items are included: Pick and Place Pick and Place Pedal........1 unit module......1 unit tool........1 unit Ref. P-405 Ref. PK-5A Ref. T260-A Cups Set ......1 unit Bent Needles Set ..1 unit Straight Needles Ref. 0940163 Ref. 0861660 Set ......
  • Page 3 Features Pick and Place Module Ref. PK-5A to Power to Ground Supply to Pedal T260-A Power LED Start/Stop Button...

  • Page 4: Tool Assembly

    Tool assembly Choose the needle and the suction cup that best fits the component and start as follows: Suction cups Needles Insert a needle and attach the appropriate cup for a correct suction process. Make sure the needle does not protrude from the cup.

  • Page 5: Operation Modes

    w w w.jbctools.com Operation modes a) Hand control Press the button to activate or stop the Hold the pen so the hole is accessible to your suction. finger tip. Suction Release Cover the pen hole with your finger and lift off Lift your finger to release the component.

  • Page 6: Pedal Control

    b) Pedal control Keep suction button off to allow pedal Keep your finger on the pen hole. function. Suction Release Press the pedal to start the suction Lift your foot to release the component...

  • Page 7: Maintenance

    Ref. 0005966 - Use original JBC spare parts only. - Do not work with defective or damaged pieces. - Repairs should only be performed by a JBC authorized technical service. - Maintenance must not be carried out by children unless supervised.
  • Page 8 Safety It is imperative to follow safety guidelines to prevent electric shock, injury, fire or explosion. - Do not use the units for any purpose other than soldering or rework. Incorrect use may cause fire. - The power cord must be plugged into approved bases. Be sure that it is properly grounded before use.
  • Page 9 w w w.jbctools.com Notes...
  • Page 10 Notes...
  • Page 11 w w w.jbctools.com 有害物质含量表 产品中有害物质的名称及含量 有害物质 部件名称 六价铬 多溴联苯 多溴二苯醚 铅(Pb) 汞(Hg) 镉(Cd) (Cr(VI)) (PBB) (PBDE) 手柄 电源线 主机 电源插座 电位连接 线路板 O 表示该有害物质在该部件所有均质材料中的含量均在GB/T 26572 规定的限量要求以下。 X 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572 规定的限量要求。...

  • Page 12: Specifications
