Falcon PREDATOR MKIII Wiring Diagram

12AmpFUSE
3 A m p F U S E
3 A m p F U S E
15 AmpFUSE
FOR(-)TRIGGERDOORLOCK
BLUE X
GREEN (-)UNLOCK
PURPLE/WHITE
GREY X
WHITE (-)LOCK
PURPLE
TOTALCLOSURE
GREY/WHITEWIREISNEGATIVETOTALCLOSUREOUTPUT
NEGATIVEOUTPUTFOR15SECONDSAFTERARMING
FALCONSECURITY Unit9,TanningCourt,Warrington,WA12HF,ENGLAND TECHNICALHELPLINE:09067001020(Allcallschargedat50p/min)
FALCON PREDATOR MKIII WIRING DIAGRAM
WHITE
WHITE
WHITE/RED
BLACK
RED
ORANGE
BROWN
GREY/WHITE
GREY
YELLOW
BLUE
GREEN
PINK
PURPLE
BLUE
GREEN
PURPLE/WHITE
GREY
WHITE
PURPLE
LED
OVERRIDESWITCH
DUALZONE
SHOCKSENSOR
OPTIONALDETECTORS
CENTRAL LOCKING CONNECTION
FOR(+)TRIGGERDOORLOCK
BLUE X
GREEN (+)UNLOCK
PURPLE/WHITE
GREY X
WHITE (+)LOCK
PURPLE
+12VDC
(+)HAZARDLIGHT(7AMP)
(+)HAZARDLIGHT(7AMP)
GROUND
(+)12VDC
(-)IMMOBILISERRELAY
(+)SIREN
(-)TOTALCLOSUREOUTPUT
(-)500mAAUXILLIARYOUTPUT"1"
IGNITION(+)
BONNETSWITCH(-)
DOORSWITCHES(-)
ANTI-HIJACKENABLE(+)TOANY(+)SWITCHORTOGGLESWITCH
DOORSWITCHES(+)
N/C
COM
UNLOCK
N/O
N/C
COM
LOCK
N/O
FORDIRECTACTUATORDRIVE
BLUE
GREEN (+)(-)UNLOCK
PURPLE/WHITE
GREY
WHITE (-)(+)LOCK
PURPLE
+12VDC
StarterSolenoid
orfuelpump
Immobiliser
(fuelpumpmustbe
Relay
immobilisedifanti-hijack
isrequired)
YELLOW BLUE
SIREN
RED BLACK
(OPTIONAL)
+12VDC
CARSWITHINTERIORLIGHTILLUMINATION
For vehicleswiththisfeatureasafactory
featureifautore-armisrequiredthedoor
switchesmustbewiredindividuallyand
a diodewillberequiredforeachline.
I f t h isisnotdoneAutore-armwillnot
function
DoorSwitch1
DoorSwitch2
DoorSwitch3
DOORINPUT
(GREEN)
oneforeach
door
FORVACUUMLOCKING
BLUE
TODOORSIDE
GREEN
+12VDC
PURPLE/WHITE
GREY
WHITE COMPRESSORSIDE
PURPLE
CUTPURPLEWHITELOOP&CONNECTGREEN&GREY
CUTCABLEFROMCOMPRESSORTODOORS&
CONNECTTOBLUE&WHITEASABOVE..
REMOVECDLJUMPERTOSETFORVACCUMLOCKING
(SEEOVERLEAF)
(+)12VDC
