C O M P L E T E
Classic Turret Press
FT 2997
QTY
1
⁄
– 18x 1½ Bolt
5
16
FT 2886
QTY
2
⁄
– 18x 1 ¼ Bolt
5
16
TF 3565
Turret Ring
TR 2460
Column
TF3567
Square Ratchet
installed
TF 3566
Auto Index Clamp
PICTURED ON Accessory
Bench Plate System
# 90251 sold separately
Pivot Pin
BP 3313
BP 2888
Connecting Link
FM 1371
⁄
– 20 Nut
7
16
BP 2774
Toggle Link
© 2018 Lee Precision Inc. TP1245
I N S T R U C T I O N S
90269
4 Hole Turret
Blind
BP 3020
Ram
BP3000
Link Pin
TR 2447
Wood knob
TP 2067
Primer
Feed
Washer
TP 2673
Square
Index Rod
FT 3128
– 18 x 3 Hex Screw
⁄
5
1 6
BP3064 Primer collection tube
(not pictured) Cap for tube # BP3127
F O R
T H E
BP3090
Lever
TP 1388
Shell Holder Insert
TP 3087
Base Casting
(not pictured)
Pivot Pin Thru BP2885
LPS Primer Arm
BP 2889A Small
BP 2889B Large
BP2777
Lever Clamp
BP2780
Lever Sleeve
BP1427
Spacer
PRINTED IN USA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lee Precision Classic Turret Press
Summary of Contents for Lee Precision Classic Turret Press
- Page 1 BP3000 BP1427 Link Pin Spacer FT 3128 – 18 x 3 Hex Screw ⁄ BP 2774 Toggle Link BP3064 Primer collection tube (not pictured) Cap for tube # BP3127 © 2018 Lee Precision Inc. TP1245 PRINTED IN USA...
- Page 2 Ammunition reloading can be dangerous if done im properly and should not CAUTION be attempted by persons not willing and able to read and fol low instructions exactly. Children should not be permitted to reload ammunition without strict parental supervision. Always wear safety glasses when reloading and shooting. Ammunition loaded with these tools and data should only be used in modern guns in good condition.
-
Page 3: D I E I N Sta L L At I O N
Slide the press frame back onto the bench to where it stops against the vertical surfaces adjacent to the FIGURE ram. Slide the lever through the lever clamp. Be Attach the Classic Turret Press to the front edge sure the lever passes completely through ¼ 5/16 of a sturdy bench using three ... - Page 4 YOU CAN NOW BEGIN RELOADING For a lifetime of service, oil the turret, ram and all pivot pins before each use The following sequence demonstrates steps necessary to load a single round. While it may look complicated, it is really only two or three strokes of the lever.
- Page 5 Firmly push trigger on the primer feed LOWER ram to seat primer. The primer should be flush, to slightly below flush, when properly seated. to dispense primer. LEE PRECISION, INC. 4275 HWY. U HARTFORD, WISCONSIN 53027 www.leeprecision.com...
- Page 6 ADJUSTING THE INDEX Cycle press down. If the turret does not stop in the correct position—follow these instructions. With the ram in the down position, place a ¼ -inch wrench on the index rod and hold in position. Now rotate the turret into the correct position.
