· Ammunition reloading can be dangerous if done im properly and can result in serious injury or death.
· Reloading rifle ammunition requires extra care due to extremely high pressures. Make sure your cases are in good condition. Inspect them before
DANGER
each reloading for damage and wear. Cases must be trimmed. An excessively long case will pinch the bullet in the end of the rifle chamber and cause
dangerously high pressure that could damage your gun and cause personal injury.
· Use only Remington™ or CCI™ primers. Other brands like Federal™, can explode with sufficient force to seriously injure the user or persons nearby.
Never place more than 100 primers in the tray.
·
Reloading should not be attempted by persons not willing and able to read and fol low instructions exactly. Do not permit distractions while loading.
This is a complex machine that needs your fullest attention.
· Children should not be permitted to reload ammunition without strict parental supervision.
· Always wear safety glasses and hearing protection when reloading and shooting.
CAUTION
· Ammunition loaded with these tools and data should only be used in modern guns in good condition. We do not accept responsibility for ammunition
loaded with these tools or data as we have no control over the manufacture and storage of components or the loading procedure and techniques.
Primers and gun powder, like gasoline and matches, can be dangerous if improperly handled or misused.
· Verify proper powder and charge for bullet weight selected.
· Be extremely careful to avoid a double charge. If in doubt, empty the case and recycle it.
Helpful setup &
operation videos
available on
leeprecision.com
Setup Tools required:
•
Safety glasses & ear protection
•
�" wrench or socket
•
Qty. 2, 7/16" wrench
•
# 1 Phillips screwdriver
•
3/16" Hex Wrench
FOLDING PRIMER TRAY
(1 included)
(2-PACK) # 90606
SHELL PLATE CARRIER
# TR3975
BASE CASTING # TR3642
PRIMER OUTLET & RETAINING RING #TP3707
RAM PIN # OF3221
PRIMER DISPOSAL TUBE # BP3064
CAP # BP3127
LEE BULLET FEEDER
OPTIONAL
Automatically feeds bullets into the mouth of the seating
die. Aligns bullets more accurately than possible by
hand. Increases cyclic rate 50 to 100%.
30 & 32 cal. Bullets up to .60 long
9mm through .365 diameter up to .46 long # 90893
9mm through .365 diameter .46 to .60 long # 90894
9mm through .365 diameter .60 to .75 long # 90895
40 cal. through .44 cal. up to .65 long
40 cal through .44 cal .65 to .80 long
45 cal. bullets .50 to .67 long
PRO 1000 3 STATION RELOADING PRESS
C O M P L E T E
OPTIONAL ACCESSORY:
CASE COLLATOR
# 90667
Powder
Measure
5-/6-18 x 1 1/4 BOLT
Qty. 3 #FT2886
PRIMER
ATTACHMENT
# 90660
OPTIONAL ACCESSORY:
BIN & BRACKET for
catching completed rounds
# 90687
I N S T R U C T I O N S
CASE FEEDER TUBES
(7-PACK) # 90661
TURRET # 90497
ACTION ROD # TR2438
TURRET RING # TP2126
CASE FEED SPRING #PR2118
FEED PLATE
RISER BLOCK
CASE SLIDER BLOCK
CONNECTING LINK #TP2129
LEVER CLAMP # OF3613
1 3/16" WASHER # OF3609
5/16 –18 X 1 1/4 BOLT # FO2113
TOGGLE ( 2 ) # OF2853
LINK BOLT (2) # TP2117
LINK NUT (2) # FB1181
Lubricate these points often:
STP
®
motor oil
treatment
# 90892
works well
Link bolt
Ram
# 90896
Link bolt
# 90897
# 90898
other chemicals, which are known
to the State of California to cause
reproductive harm and cancer. For
more information, go to
www.P65Warnings.ca.gov.
lead and other elements which are
known to the State of California
to cause reproductive harm and
cancer. For more information, go
to www.P65Warnings.ca.gov. To
prevent exposure, do not alter the
product by welding, grinding, etc.
OPTIONAL ACCESSORY:
RELOADING STAND
# 90688
Rust proof these points often:
Ram pin
WARNING: Handling live
primers and spent primers
may expose you to lead or
WARNING: This product
may contain steel alloyed
with trace amounts of
Dry Coat
®
rust
preventative
works well
Turret ring
(3)
Columns
Handle & lever clamp
Advertisement
Table of Contents
Related Manuals for Lee Precision PRO 1000
Summary of Contents for Lee Precision PRO 1000
- Page 1 PRO 1000 3 STATION RELOADING PRESS C O M P L E T E I N S T R U C T I O N S · Ammunition reloading can be dangerous if done im properly and can result in serious injury or death.
- Page 2 Mount your press. The most convenient way to mount your press is with our Lee Bench # 90251 Bench Plate Plate System # 90251. This system includes all of the mounting hardware and allows for quick press removal without unbolting from bench. Or, purchase (3) 1/4” bolts and nuts and prepare your workbench for use with this press using the drill template available: leeprecision.com/cgi-data/instruct/PROVTP.pdf.
- Page 3 Handgun Powder Through Expanding Rifle Short Charging Die (position # 2) FIG 5 position This die only ships inside the 223 Remington Pro 1000 Spin the lock-ring up to the top of the rifle short (position # 2) charging die.
- Page 4 However, ONLY those primers manufactured by CCI™ or Remington™ are recommended for use in the Pro 1000—and when loading those primers—safety glasses and hearing protection must be used. NO OTHER PRIMERS should be used with the Pro 1000.
- Page 5 Before attaching the 4 tube case feeder, place an empty case in front of the case slider. Process 50-100 cases until you have the feel of the entire reloading sequence. Be sure to measure your completed ammunition to verify it is the correct overall length and will chamber in your firearm.
- Page 6 CHANGING SHELL PLATE ONLY Lower carrier so Remove the trough and Install shell plate and tighten the carrier pin pases priming pin and clean out any drive bolt by rotating the action rod With your case slider block through shell plate accumulated primer dust or counterclockwise.
- Page 7 INSTALLING THE SHELL PLATE CARRIER The carrier is attached to the ram with a single socket head screw. This makes it very easy to change the entire carrier for caliber changing. Push the action rod through the carrier from Be sure to keep the primer trough pin Re-install turret with dies and raise your behind the right rear column.
- Page 8 Any Lee product of current manufacture, regardless of age or condition, will be recon di tioned to new, including a new guarantee, if LEE PRECISION, INC. 4275 HWY. U HARTFORD WISCONSIN 53027 www.leeprecision.com...
