KIT SHOWN
Auto-Drum
Powder Measure
# 90811
FOLDING PRIMER TRAY
1 included
#90606 (2 pack)
PRIMER TROUGH & SLIDER
#BP5079
#91980
Small
PRIMER
GUIDES
#91981
Large
INDEX ROD
#BP5087
CASE EJECTOR
#BP5086
BASE
BRACKET
#BP5086
CONNECTING LINK (2)
#BP2888
7⁄ 1 8-20 NUT
#FM1371
LINK PIN
#BP3000
TOGGLE (2)
#BP2774
PRIMER COLLECTION TUBE
#BP3064
CAP FOR COLLECTION TUBE
#BP3127
(NOT PICTURED)
Six Pack Progressive | Six Pack Pro Kit
I N S T R U C T I O N S
Universal Case Feeder
# 90242
PRIMER FEED SPRING
# PR5343
CASE FEED SPRING
# PR2118
RAM
LEVER CLAMP 10°
#BP5101
LEVER SLEEVE 10°
SPACER
#BP5090
#BP1427
DANGER
Ammunition reloading can be dangerous if done im properly and
can result in serious injury or death.
· Reloading should not be attempted by persons not willing and
able to read and fol low instructions exactly.
· Children should not be permitted to reload ammunition without
strict parental supervision.
· Always wear safety glasses and hearing protection when
reloading and shooting.
CAUTION
· Ammunition loaded with these tools and data should only be
used in modern guns in good condition.
· We do not accept responsibility for ammunition loaded with
these tools or data as we have no control over the manufacture
and storage of components or the loading procedure and
techniques.
· Primers and gun powders, like gasoline and matches, can be
dangerous if improperly handled or misused.
LUBRICATION
POINTS
use STP™ motor oil
treatment or motor
oil on link pins and
ram
SLIDER BLOCK
#90479
Bin
# 90687
Breech Lock Die Set
Kits includes new Breech
Lock Die Set. Utilizes an
integrated o-ring to keep
dies firmly in place, yet
remain finger adjustable.
Color coded for easy
identification. The best
value for Lee Breech
Lock press owners.
Die wrench included
Works on
spline drive
breech lock
bushings
and lock
rings.
LEE PRECISION, INC.
4275 Hwy. U · Hartford WI 53027
www.leeprecision.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Six Pack Progressive and is the answer not in the manual?

Questions and answers

Summary of Contents for Lee Precision Six Pack Progressive

  • Page 1 Six Pack Progressive | Six Pack Pro Kit I N S T R U C T I O N S DANGER Ammunition reloading can be dangerous if done im properly and can result in serious injury or death. KIT SHOWN ·...
  • Page 2 SAFETY CONSIDERATIONS SMOOTH OPERATING TIPS SETUP TOOLS REQUIRED •  B e sure of proper powder and charge for •  A lways move the lever smoothly in complete •  S afety glasses & ear protection bullet weight selected. strokes. An interrupted stroke can cause • ...
  • Page 3 INSTALL SHELL PLATE Installing or changing shell plate. See top of page 5 for listing. Lower carrier to bottom of Remove Breech Lock Bushing Remove case ejector the stroke then raise slightly Die from station 4 to access the remove index rod. index rod.
  • Page 4 TOOL HEAD POSITION & INITIAL SETUP We suggest Lee dies as they use a powder through expanding die to conveniently charge your brass while expanding the case mouth. Lock rings are not required when utilizing the spline drive breech lock bushing. Follow the reloading die instructions for the type and brand of dies you have selected.
  • Page 5 Shell Shell SHELL PLATE LISTING SHELL PLATE LISTING Product # Product # Plate Plate 38 SPECIAL, 357 MAG 38 SPECIAL, 357 MAG 1S 1S 91835 91835 Position 3 45 ACP, 30/06, 308, 6.5 CREED 45 ACP, 30/06, 308, 6.5 CREED 2L 2L 91836 91836...
  • Page 6: Troubleshooting

    Install primer feeder IMPORTANT - Fill the primer feed tray. View help video for loading primers into tray: Don’t let the primer level fall below the tray level. Once the last primer has exited the folding tray, replenish the primer supply, or else you will be loading cases without primers.
  • Page 7 Install case feeder Reference grid on top of page 8 for setup instructions Assembled as a SMALL feed plate Assembled as a LARGE feed plate small plug removed small small hole hole large large hole hole small plug installed storage spot for small plug Bolt and nuts are adjacent to small through hole and the small plug.
  • Page 8 CARTRIDGE CHANGE OVER To convert the Six Pack Pro from a one cartridge to another, you will need the proper shell plate and appropriate Lee reloading die set. The chart below shows proper configuration with catalog numbers. Shell Shell Shell Plate Shell Plate Univ.
